Tractor · 2009Unverified
Kubota JB19X-PC Power Crawler
Kubota JB19X-PC Power Crawler — JB Bullstar Extra Series · 19 hp. Reference specifications; pending source verification.
The Kubota JB19X-PC Power Crawler is a tractor rated at 19 hp — making it one of the more compact options in its class. It was manufactured in 2009. Power comes from a 3-cylinder diesel liquid-cooled engine, driving through a tracked undercarriage with a 6-speed gearbox. Listed weight is 744 kg, and it is aimed at jobs of around up to 200 ac. The available specification table below shows both UK and US units.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
19 hp
Weight
744 kg
Catalogue coverage
Variants represented
2
Richest spec table
43 rows
Recorded power
19 hp
Recorded weight
744 kg
Transmissions
6-speed
Production years
2009-2009
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS.Reference
Variants
JB19XwheeledReference
JB19X-PChalf-trackReference
Engine
Kubota 1.0L 3-cyl dieselReference
Fuel tank14.0 LReference
Engine14.0 kWReference
Kubota D1005Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Bore/Stroke76 x 74 mmReference
Power14.0 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speedReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
Three gears, plus reverse, in two ranges.Reference
PTO & Hydraulics
Rear Type0Reference
Rear PTO540 (1.375)Reference
Rear PTO Type551:2600Reference
Rear PTO Type967:2600Reference
Dimensions
Wheelbase127 cmReference
Weight744 kgReference
Front tire6-14Reference
Rear tiretracksReference
Ag front6-14Reference
Ag rear330mm trackReference
Length201 cmReference
Width120 cmReference
Height193 cmReference
Ground clearance33 cmReference
Front tread88 cmReference
Rear tread88 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
