Tractor · 2005Unverified

Kubota KB18

Name: Kubota KB18
Brand: Kubota

Kubota KB18 — KB Kingbull Series · 18 hp. Reference specifications; pending source verification.

The Kubota KB18 is a compact tractor with a rating of 18 hp, making it a suitable option for smaller-scale operations. It was produced from 2005 to 2007 and features a 3-cylinder diesel liquid-cooled engine, paired with a powershift transmission and four-wheel drive system. The tractor's listed weight ranges from 1532 to 1587 pounds. It is designed for use on plots of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

18 hp

Weight

1532 to 1587 pounds

Catalogue coverage

Variants represented

Richest spec table

49 rows

Recorded power

18 hp

Recorded weight

694 kg

Transmissions

9-speed

Production years

2005-2007

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Sub-Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post ROPS.Reference

Engine

Kubota 1.0L 3-cyl dieselReference

Fuel tank26.9 LReference

Engine13.2 kWReference

Kubota D1005Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.0 LReference

Bore/Stroke76 x 74 mmReference

Power13.2 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

9-speedReference

36-speed power shiftReference

Gear Weight694 kgReference

Gears9 forward and reverseReference

Clutchdry discReference

Three gears (1-3) in three ranges with shuttle shift.Reference

TransmissionGlideshiftReference

Typepower shiftReference

Gears36 forward and 24 reverseReference

Sequential hydraulically-shifted transmission. Twelve forward gears with three ranges. Tractor must be stopped, and clutch used, to shift ranges.Reference

PTO & Hydraulics

Rear Type0Reference

Rear PTO Type540 (1.375)Reference

Engine RPM530@2600Reference

Engine RPM799@2600Reference

Engine RPM1182@2600Reference

Engine RPM-662@2600Reference

Dimensions

Wheelbase135 cmReference

Weight1532 to 1587 poundsReference

Front tire6.00-12Reference

Rear tire8.3-22Reference

Standard tires (ag)Front: 6.00-12. Rear: 8.3-22Reference

Length234 cmReference

Width107 cmReference

Height (ROPS)189 cmReference

Glideshift Weight719 kgReference

Ground clearance35 cmReference

Front tread84 cmReference

Rear tread81/89 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
