Tractor · 2008Unverified
Kubota KB185
Kubota KB185 — KB Kingbull Series · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
1532 to 1587 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Sub-Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post ROPS.Reference
Variants
KB185wheeledReference
KB185-PChalf-trackReference
Engine
Kubota 1.0L 3-cyl dieselReference
Fuel tank26.9 LReference
Engine13.6 kWReference
Kubota D1005Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Bore/Stroke76 x 74 mmReference
Power13.6 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
9-speedReference
36-speed power shiftReference
Gear Weight694 kgReference
Gears9 forward and reverseReference
Clutchdry discReference
Three gears (1-3) in three ranges with shuttle shift.Reference
TransmissionGlideshiftReference
Typepower shiftReference
Gears36 forward and 24 reverseReference
Sequential hydraulically-shifted transmission. Twelve forward gears with three ranges. Tractor must be stopped, and clutch used, to shift ranges.Reference
PTO & Hydraulics
Rear Type0Reference
Rear PTO Type540 (1.375)Reference
Engine RPM530@2600Reference
Engine RPM799@2600Reference
Engine RPM1182@2600Reference
Engine RPM-662@2600Reference
Dimensions
Wheelbase135 cmReference
Weight1532 to 1587 poundsReference
Front tire6.00-12Reference
Rear tire8.3-22Reference
Standard tires (ag)Front: 6.00-12. Rear: 8.3-22Reference
Length234 cmReference
Width104 cmReference
Height (ROPS)189 cmReference
Glideshift Weight719 kgReference
Ground clearance35 cmReference
Front tread85 cmReference
Rear tread81/89 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
