Tractor · 2008Unverified

Kubota KB185-PC

Name: Kubota KB185-PC
Brand: Kubota

Kubota KB185-PC — KB Kingbull Series · 18 hp. Reference specifications; pending source verification.

The Kubota KB185-PC is a tractor model with a power rating of approximately 18 hp, positioning it at the lower end of its class. Produced from 2008 to 2009, the KB185-PC is equipped with a 3-cylinder diesel liquid-cooled engine and a tracked undercarriage paired with a powershift transmission. It has a listed operating weight of 1863 to 1918 pounds, and its capabilities allow for operations on up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

18 hp

Weight

1863 to 1918 pounds

Catalogue coverage

Variants represented

Richest spec table

52 rows

Recorded power

18 hp

Recorded weight

845 kg

Transmissions

9-speed

Production years

2008-2009

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Half-track Crawler tractorReference

Drivehalf-trackReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post ROPS.Reference

Variants

KB185wheeledReference

KB185-PChalf-trackReference

Engine

Kubota 1.0L 3-cyl dieselReference

Fuel tank14.0 LReference

Engine13.6 kWReference

Kubota D1005Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.0 LReference

Bore/Stroke76 x 74 mmReference

Power13.6 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

9-speedReference

36-speed power shiftReference

Gear Weight845 kgReference

Gears9 forward and reverseReference

Clutchdry discReference

Three gears (1-3) in three ranges with shuttle shift.Reference

TransmissionGlideshiftReference

Typepower shiftReference

Gears36 forward and 24 reverseReference

Sequential hydraulically-shifted transmission. Twelve forward gears with three ranges. Tractor must be stopped, and clutch used, to shift ranges.Reference

PTO & Hydraulics

Rear Type0Reference

Rear PTO Type540 (1.375)Reference

Engine RPM530@2600Reference

Engine RPM799@2600Reference

Engine RPM1182@2600Reference

Engine RPM-662@2600Reference

Dimensions

Wheelbase135 cmReference

Weight1863 to 1918 poundsReference

Front tire6-14Reference

Rear tiretracksReference

Ag front6-14Reference

Ag rear330mm trackReference

Length236 cmReference

Width125 cmReference

Height (ROPS)197 cmReference

Glideshift Weight870 kgReference

Ground clearance37 cmReference

Front tread102 cmReference

Rear tread92 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
