Tractor · 2009Unverified

Kubota KB23X-PC

Name: Kubota KB23X-PC
Brand: Kubota

Kubota KB23X-PC — KB Kingbull Extra Series · 22 hp. Reference specifications; pending source verification.

The Kubota KB23X-PC is a compact tractor rated at 22 horsepower. Manufactured between 2009 and 2014, it features a 3-cylinder diesel liquid-cooled engine driving a tracked undercarriage with a powershift transmission. The listed weight ranges from 1940 to 2304 pounds. It is suitable for tasks covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

22 hp

Weight

1940 to 2304 pounds

Catalogue coverage

Variants represented

Richest spec table

57 rows

Recorded power

22 hp

Transmissions

9-speed

Production years

2009-2014

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Half-track Crawler tractorReference

Drivehalf-trackReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post ROPS.Reference

Variants

KB23XwheeledReference

KB23X-PChalf-trackReference

Engine

Kubota 1.3L 3-cyl dieselReference

ROPS Fuel tank26.9 LReference

Cab Fuel tank21.2 LReference

Engine16.5 kWReference

Kubota D1305Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.3 LReference

Bore/Stroke79 x 89 mmReference

Power16.5 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

9-speedReference

36-speed power shiftReference

ROPS gear879 kgReference

Cab gear1035 kgReference

Gears9 forward and reverseReference

Clutchdry discReference

Three gears (1-3) in three ranges with shuttle shift.Reference

TransmissionGlideshiftReference

Typepower shiftReference

Gears36 forward and 24 reverseReference

Sequential hydraulically-shifted transmission. Twelve forward gears with three ranges. Tractor must be stopped, and clutch used, to shift ranges.Reference

PTO & Hydraulics

Rear Type0Reference

Rear PTO Type540 (1.375)Reference

Engine RPM530@2600Reference

Engine RPM799@2600Reference

Engine RPM1182@2600Reference

Engine RPM-662@2600Reference

Dimensions

ROPS Wheelbase135 cmReference

Cab Wheelbase136 cmReference

Weight1940 to 2304 poundsReference

Front tire7-16Reference

Rear tiretracksReference

Ag front7-16Reference

Ag rear330mm trackReference

Length236 cmReference

Width125 cmReference

Height (ROPS)197 cmReference

Height (cab)202 cmReference

Ground clearance37 cmReference

Front tread94 cmReference

Rear tread92 cmReference

ROPS Glideshift889 kgReference

Cab Glideshift1045 kgReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
