Tractor · 1999Unverified

Kubota KL28 Hi-Speed

Name: Kubota KL28 Hi-Speed
Brand: Kubota

Kubota KL28 Hi-Speed — KL Series · 28 hp. Reference specifications; pending source verification.

The Kubota KL28 Hi-Speed is a tractor with a rated engine power of approximately 28 hp, positioning it at the lower end of its class. It was manufactured between 1999 and 2005. The model features a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a 20-speed gearbox. Its operating weight ranges from 2734 to 3219 pounds, and it is suitable for operations covering areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

28 hp

Weight

2734 to 3219 pounds

Catalogue coverage

Variants represented

Richest spec table

53 rows

Recorded power

28 hp

Recorded weight

1240 kg

Transmissions

20-speed

Production years

1999-2005

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post ROPS. Cab optional.Reference

Engine

Kubota 1.6L 3-cyl dieselReference

Fuel tank35.0 LReference

Engine20.6 kWReference

Kubota D1703Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.6 LReference

Bore/Stroke87 x 92 mmReference

Power20.6 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

20-speedReference

30-speedReference

Gears20 forward and reverseReference

Four gears (1-4) in two ranges with three-range shift (creeper, medium, and high-speed).Reference

Gears30 forward and 20 reverseReference

Twelve gears in three ranges (creeper, medium, and high-speed) with shuttle shift. Only gears 1-8 available in reverse. In high-speed range only gears six forward and four reverse gears available.Reference

PTO & Hydraulics

Rear TypeIReference

Rear PTO Type540 (1.375)Reference

Engine RPM564@2600Reference

Engine RPM795@2600Reference

Engine RPM985@2600Reference

Engine RPM1313@2600Reference

Engine RPM-985@2600Reference

Dimensions

ROPS Wheelbase167 cmReference

Cab Wheelbase171 cmReference

Weight2734 to 3219 poundsReference

Front tire7-16Reference

ROPS Rear tire11.2-24Reference

ROPS Standard tires (ag)Front: 7-16. Rear: 11.2-24Reference

Cab. Rear: Standard tires (ag)Front: 11.2-26Reference

ROPS Length308 cmReference

Cab Length314 cmReference

ROPS Width135 cmReference

Cab Width137 cmReference

Height (ROPS)198 cmReference

Height (cab)207 cmReference

ROPS Weight1240 kgReference

Cab Weight1460 kgReference

Ground clearance34 cmReference

Front tread107 cmReference

ROPS Rear tread104/116 cmReference

Cab Rear tread104 to 144 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
