Tractor · 2008Unverified
Kubota KL285
Kubota KL285 — KL Series · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
2833 to 3285 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Variants
KL285standardReference
KL285Hhigh-speedReference
Engine
Kubota 1.6L 3-cyl dieselReference
Fuel tank36.0 LReference
Engine20.6 kWReference
Kubota D1703Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke87 x 92 mmReference
Power20.6 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
24-speedReference
Gears16 forward and reverseReference
Four gears (1-4) in two ranges with additional creeper range and shuttle shift.Reference
Gears24 forward and 16 reverseReference
Twelve gears in two ranges (creeper and high) with shuttle shift. Only eight gears available in reverse.Reference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM561@2700Reference
Engine RPM791@2700Reference
Engine RPM980@2700Reference
Engine RPM1307@2700Reference
Engine RPM-980@2700Reference
Dimensions
Wheelbase171 cmReference
Weight2833 to 3285 poundsReference
Front tire7-16Reference
Rear tire12.4-24Reference
Standard tires (ag)Front: 7-16. Rear: 12.4-24Reference
Length313 cmReference
Width137 cmReference
Height (ROPS)195 cmReference
Height (cab)212 cmReference
ROPS Weight1285 kgReference
Cab Weight1490 kgReference
Ground clearance34 cmReference
Front tread107 cmReference
Rear tread106/137 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
