Tractor · 2010Unverified

Kubota KL2850-PC

Name: Kubota KL2850-PC
Brand: Kubota

Kubota KL2850-PC — KL Kingwel 50 Series · 28 hp. Reference specifications; pending source verification.

The Kubota KL2850-PC is a tractor model with a rating of approximately 28 horsepower, positioning it at the lighter end of its class. Manufactured from 2010 to 2011, the tractor features a 3-cylinder diesel liquid-cooled engine and is equipped with a tracked undercarriage paired to a 24-speed gearbox. Its operating weight ranges between 3384 and 3748 pounds, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

28 hp

Max power

27.6 hp

Weight

3384 to 3748 pounds

Catalogue coverage

Variants represented

Richest spec table

72 rows

Recorded power

28 hp

Recorded weight

1534 kg

Transmissions

24-speed

Production years

2010-2011

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Half-track Crawler tractorReference

Drivehalf-trackReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post ROPS. Cab optional with air-conditioning.Reference

Engine

Kubota 1.6L 3-cyl dieselReference

Fuel tank36.0 LReference

Engine20.6 kWReference

Kubota D1703Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.6 LReference

Bore/Stroke86 x 91 mmReference

Power20.6 kWReference

Rated RPM2700Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders3 cylinderReference

Rated engine speed2,700 RPMReference

Bore and stroke3.4x3.6 inchesReference

Cooling systemliquid-cooledReference

Transmission

24-speedReference

Gears24 forward and 16 reverseReference

Clutchdry discReference

forward and reverse options24F and 16RReference

PTO & Hydraulics

Rear TypeIReference

Rear PTO Type540 (1.375)Reference

Engine RPM561@2700Reference

Engine RPM791@2700Reference

Engine RPM980@2700Reference

Engine RPM1307@2700Reference

Engine RPM-980@2700Reference

Dimensions

Wheelbase167 cmReference

Weight3384 to 3748 poundsReference

Front tire8-16Reference

Rear tiretracksReference

Ag front8-16Reference

Ag rear400mm tracksReference

Length322 cmReference

Width157 cmReference

Height (ROPS)203 cmReference

Height (cab)218 cmReference

ROPS Weight1534 kgReference

Cab Weight1700 kgReference

Ground clearance39 cmReference

Front tread108 cmReference

Rear tread118 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

General

Make & ModelKubotaReference

Rollover protective structureTwo-post ROPSReference

Capacities

Capacity100.5 ciReference

Power

Max Power27.6 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Engine Speed on Rear PTO speed1,307@2,700 RPMReference

Steering & brakes

Brakesmechanical wet discReference

Steering typepowerReference

Hydraulics

Rear Hitch category (SAE designation)Category IReference

Dimensions & weight

Height Over Cab218.9 cmReference

Height Over ROPS203.5 cmReference

Overall Length322.6 cmReference

Overall Width158 cmReference

Overall weight1,535 kgReference

Wheels & tyres

Rear Wheel Type400mm tracksReference

Rear wheel tread range118.1 cmReference

Front Wheel Type45,520Reference

Front Wheel tread range108.5 cmReference

Operator station

Cab AvailabilityAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
