Tractor · 2012Unverified

Kubota KL28R-PC

Name: Kubota KL28R-PC
Brand: Kubota

Kubota KL28R-PC — KL Kingwel R Series · 28 hp. Reference specifications; pending source verification.

The Kubota KL28R-PC is a compact tractor model with a rated power output of 28 hp, making it a suitable option for smaller-scale farming operations. Manufactured between 2012 and 2015, this model features a 3-cylinder diesel liquid-cooled engine, with a tracked undercarriage and powershift transmission configuration. The listed weight of the Kubota KL28R-PC ranges from 3417 to 3880 pounds. It is designed to handle tasks of approximately up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

28 hp

Max power

27.6 hp

Weight

3417 to 3880 pounds

Catalogue coverage

Variants represented

Richest spec table

76 rows

Recorded power

28 hp

Recorded weight

1549 kg

Transmissions

24-speed power shift

Production years

2012-2015

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Half-track Crawler tractorReference

Drivehalf-trackReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post ROPS. Cab optional with air-conditioning.Reference

Engine

Kubota 1.6L 3-cyl dieselReference

Fuel tank36.0 LReference

Engine20.6 kWReference

Kubota D1703Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.6 LReference

Bore/Stroke86 x 91 mmReference

Power20.6 kWReference

Rated RPM2700Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders3 cylinderReference

Rated engine speed2,700 RPMReference

Bore and stroke3.4x3.6 inchesReference

Cooling systemliquid-cooledReference

Transmission

24-speed power shiftReference

TransmissionGlideshiftReference

Typepower shiftReference

Gears24 forward and 16 reverseReference

Clutchdry discReference

Twelve hydraulically-shift gears (eight in reverse) in two ranges.Reference

Transmission TypePowershiftReference

forward and reverse optionsGlideshift 24-F and 16-RReference

PTO & Hydraulics

Rear TypeIReference

Rear PTO Type540 (1.375)Reference

Engine RPM561@2700Reference

Engine RPM791@2700Reference

Engine RPM980@2700Reference

Engine RPM1307@2700Reference

Engine RPM-980@2700Reference

Dimensions

Wheelbase169 cmReference

Weight3417 to 3880 poundsReference

Front tire8-16Reference

Rear tiretracksReference

Ag front8-16Reference

Ag rear400mm tracksReference

Length312 cmReference

Width154 cmReference

Height (ROPS)202 cmReference

Height (cab)219 cmReference

ROPS Weight1549 kgReference

Cab Weight1759 kgReference

Ground clearance39 cmReference

Front tread108 cmReference

Rear tread115 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

General

Make & ModelKubotaReference

Rollover protective structureTwo-post ROPS.Reference

Capacities

Capacity100.5 ciReference

Power

Max Power27.6 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Engine Speed on Rear PTO speed1,307@2,700 RPMReference

Steering & brakes

Brakesmechanical wet discReference

Steering typepowerReference

Hydraulics

Rear Hitch category (SAE designation)Category IReference

Dimensions & weight

Height Over ROPS202.4 cmReference

Height Over Cab219.5 cmReference

Overall Length312.9 cmReference

Overall Width154.9 cmReference

Overall weight1,549.9 kgReference

Wheels & tyres

Rear Wheel Type400mm tracksReference

Rear wheel tread range115.1 cmReference

Front Wheel Type45,520Reference

Front Wheel tread range108.5 cmReference

Operator station

Cab AvailabilityAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
