Tractor · 2006Unverified

Kubota KL300

Name: Kubota KL300
Brand: Kubota

Kubota KL300 — KL Series · 30 hp. Reference specifications; pending source verification.

The Kubota KL300 is a compact tractor with a rated power output of 30 hp, placing it amongst the smaller options in its class. Manufactured between 2006 and 2007, this model features a 3-cylinder diesel liquid-cooled engine, coupled with a 16-speed gearbox and four-wheel drive. The listed operating weights for the Kubota KL300 range from 2910 to 3296 pounds. It is suitable for tasks on land areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

30 hp

Weight

2910 to 3296 pounds

Catalogue coverage

Variants represented

Richest spec table

49 rows

Recorded power

30 hp

Recorded weight

1319 kg

Transmissions

16-speed

Production years

2006-2007

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post ROPS. Cab optional.Reference

Engine

Kubota 1.5L 3-cyl dieselReference

Fuel tank40.1 LReference

Engine22.1 kWReference

Kubota D1503Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke83 x 92 mmReference

Power22.1 kWReference

Rated RPM2700Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speedReference

24-speedReference

Gears16 forward and reverseReference

Four gears (1-4) in two ranges with additional creeper range and shuttle shift.Reference

Eight gears in two ranges (creeper and high) with shuttle shift.Reference

Gears24 forward and 16 reverseReference

Twelve gears in two ranges (creeper and high) with shuttle shift. Only eight gears available in reverse. 24-speed transmission only on tractors with cabin.Reference

PTO & Hydraulics

Rear TypeIReference

Rear PTO Type540 (1.375)Reference

Engine RPM541@2700Reference

Engine RPM763@2700Reference

Engine RPM945@2700Reference

Engine RPM1260@2700Reference

Engine RPM-945@2700Reference

Dimensions

Wheelbase174 cmReference

Weight2910 to 3296 poundsReference

Front tire8-16Reference

Rear tire12.4-26Reference

Standard tires (ag)Front: 8-16. Rear: 12.4-26Reference

Length318 cmReference

Width141 cmReference

Height (ROPS)198 cmReference

Height (cab)198 cmReference

ROPS Weight1319 kgReference

Cab Weight1495 kgReference

Ground clearance36 cmReference

Front tread113 cmReference

Rear tread108 to 148 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
