Tractor · 2010Unverified
Kubota KL3150
Kubota KL3150 — KL Kingwel 50 Series · 31 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
31 hp
Weight
2932 to 3384 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post ROPS. Cab optional with air-conditioning.Reference
Engine
Kubota 1.8L 3-cyl dieselReference
Fuel tank40.1 LReference
Engine22.8 kWReference
Kubota D1803Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke86 x 102 mmReference
Power22.8 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
24-speed power shiftReference
30-speedReference
Gears16 forward and reverseReference
Clutchdry discReference
Four gears(1-4) in two ranges, with additional creeper range and shuttle shift.Reference
TransmissionGlideshiftReference
Typepower shiftReference
Gears24 forward and 16 reverseReference
Twelve hydraulically-shift gears (eight in reverse) in two ranges.Reference
Gears30 forward and 20 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM541@2700Reference
Engine RPM760@2700Reference
Engine RPM945@2700Reference
Engine RPM1260@2700Reference
Engine RPM-945@2700Reference
Dimensions
Wheelbase174 cmReference
Weight2932 to 3384 poundsReference
Front tire6-14Reference
Rear tire9.5-24Reference
Standard tires (ag)Front: 6-14. Rear: 9.5-24Reference
Length318 cmReference
Width141 cmReference
Height (ROPS)198 cmReference
Height (cab)215 cmReference
ROPS Weight1329 kgReference
Cab Weight1534 kgReference
Ground clearance36 cmReference
Front tread113 cmReference
Rear tread108/135 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
