Tractor · 2012Unverified

Kubota KL31R-PC

Name: Kubota KL31R-PC
Brand: Kubota

Kubota KL31R-PC — KL Kingwel R Series · 31 hp. Reference specifications; pending source verification.

The Kubota KL31R-PC is a compact tractor with a rated output of 31 hp, one of the smaller options in its class. It was manufactured from 2012 to 2015. The tractor features a 3-cylinder diesel liquid-cooled engine and a tracked undercarriage with a powershift transmission, weighing between 3417 and 3880 pounds. Its intended application is for jobs covering areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

31 hp

Weight

3417 to 3880 pounds

Catalogue coverage

Variants represented

Richest spec table

51 rows

Recorded power

31 hp

Recorded weight

1549 kg

Transmissions

24-speed power shift

Production years

2012-2015

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Half-track Crawler tractorReference

Drivehalf-trackReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post ROPS. Cab optional with air-conditioning.Reference

Variants

KL31RwheeledReference

KL31R-PChalf-trackReference

Engine

Kubota 1.8L 3-cyl dieselReference

Fuel tank36.0 LReference

Engine22.8 kWReference

Kubota D1803Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.8 LReference

Bore/Stroke86 x 102 mmReference

Power22.8 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

24-speed power shiftReference

TransmissionGlideshiftReference

Typepower shiftReference

Gears24 forward and 16 reverseReference

Clutchdry discReference

Twelve hydraulically-shift gears (eight in reverse) in two ranges.Reference

PTO & Hydraulics

Rear TypeIReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2600Reference

Engine RPM762@2700Reference

Engine RPM944@2600Reference

Engine RPM1258@2600Reference

Engine RPM-944@2600Reference

Dimensions

Wheelbase169 cmReference

Weight3417 to 3880 poundsReference

Front tire8-16Reference

Rear tiretracksReference

Ag front8-16Reference

Ag rear400mm tracksReference

Length312 cmReference

Width154 cmReference

Height (ROPS)202 cmReference

Height (cab)219 cmReference

ROPS Weight1549 kgReference

Cab Weight1759 kgReference

Ground clearance39 cmReference

Front tread108 cmReference

Rear tread115 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
