Tractor · 2012Unverified
Kubota KL31Z-PC
Kubota KL31Z-PC — KL Kingwel Zero Series · 31 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
31 hp
Weight
1910 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Mechanical wet disc brakesReference
Cab standard with air-conditioning.Reference
Variants
KL31ZwheeledReference
KL31Z-PChalf-trackReference
Engine
Kubota 1.8L 3-cyl dieselReference
Fuel tank40.1 LReference
Engine22.8 kWReference
Kubota D1803Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke86 x 102 mmReference
Power22.8 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
continuously-varaible transmissionReference
TransmissionDual DriveReference
Typecontinuously-varaible transmissionReference
Gearsinfinite forward and reverse (2-range)Reference
Clutchdry discReference
Hydro-mechanical CVT.Reference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM562@2700Reference
Engine RPM796@2700Reference
Engine RPM998@2700Reference
Engine RPM1337@2700Reference
Engine RPM-793@2700Reference
Dimensions
Wheelbase176 cmReference
Weight1910 kgReference
Front tire8-16Reference
Rear tiretracksReference
Ag front8-16Reference
Ag rear400mm trackReference
Length321 cmReference
Width167 cmReference
Height (cab)227 cmReference
Ground clearance39 cmReference
Front tread108 cmReference
Rear tread127 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
