Tractor · 2010Unverified
Kubota KL3450-PC
Kubota KL3450-PC — KL Kingwel 50 Series · 34 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
34 hp
Weight
3516 to 3836 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post ROPS. Cab optional with air-conditioning.Reference
Variants
KL3450wheeledReference
KL3450-PChalf-trackReference
Engine
Kubota 1.8L 3-cyl dieselReference
Fuel tank40.1 LReference
Engine25.0 kWReference
Kubota D1803Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke86 x 102 mmReference
Power25.0 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speedReference
Gears24 forward and 16 reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM577@2700Reference
Engine RPM814@2700Reference
Engine RPM1009@2700Reference
Engine RPM1345@2700Reference
Engine RPM-1009@2700Reference
Dimensions
Wheelbase173 cmReference
Weight3516 to 3836 poundsReference
Front tire8-18Reference
Rear tiretracksReference
Ag front8-18Reference
Ag rear400mm tracksReference
Length334 cmReference
Width157 cmReference
Height (ROPS)204 cmReference
Height (cab)220 cmReference
ROPS Weight1594 kgReference
Cab Weight1740 kgReference
Ground clearance40 cmReference
Front tread117 cmReference
Rear tread118 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
