Tractor · 2006Unverified

Kubota KL360

Name: Kubota KL360
Brand: Kubota

Kubota KL360 — KL Series · 36 hp. Reference specifications; pending source verification.

The Kubota KL360 is a tractor model rated at approximately 36 hp, falling within the lower power range of its class. Production of the KL360 took place from 2006 to 2007. Its powertrain consists of a 3-cylinder diesel liquid-cooled engine coupled with four-wheel drive and a 16-speed gearbox. The tractor has an operating weight of 3285 to 3682 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

36 hp

Weight

3285 to 3682 pounds

Catalogue coverage

Variants represented

Richest spec table

48 rows

Recorded power

36 hp

Recorded weight

1490 kg

Transmissions

16-speed

Production years

2006-2007

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post ROPS. Cab optional.Reference

Engine

Kubota 1.5L 3-cyl dieselReference

Fuel tank40.1 LReference

Engine26.5 kWReference

Kubota D1503Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke83 x 92 mmReference

Power26.5 kWReference

Rated RPM2700Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speedReference

24-speedReference

Gears16 forward and reverseReference

Four gears (1-4) in two ranges with additional creeper range and shuttle shift.Reference

Gears24 forward and 16 reverseReference

Twelve gears in two ranges (creeper and high) with shuttle shift. Only eight gears available in reverse.Reference

PTO & Hydraulics

Rear TypeIReference

Rear PTO Type540 (1.375)Reference

Engine RPM533@2700Reference

Engine RPM752@2700Reference

Engine RPM931@2700Reference

Engine RPM1241@2700Reference

Engine RPM-931@2700Reference

Dimensions

Wheelbase191 cmReference

Weight3285 to 3682 poundsReference

Front tire8-18Reference

Rear tire12.4-28Reference

Standard tires (ag)Front: 8-18. Rear: 12.4-28Reference

Length346 cmReference

Width147 cmReference

Height (ROPS)198 cmReference

Height (cab)198 cmReference

ROPS Weight1490 kgReference

Cab Weight1670 kgReference

Ground clearance36 cmReference

Front tread118 cmReference

Rear tread114 to 143 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
