Kubota KL37Z
Kubota KL37Z — KL Kingwel Zero Series · 37 hp. Reference specifications; pending source verification.
The Kubota KL37Z is a compact tractor with a rated output of 37 hp, positioning it among smaller options in its class. Produced from 2012 to 2015, the KL37Z features a 4-cylinder diesel liquid-cooled engine powering a four-wheel drive system with a continuously variable transmission. Its listed weight is 1809 kg, making it suitable for tasks involving up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Max power
36.5 hp
Weight
1809 kg
Catalogue coverage
Variants represented
2
Richest spec table
72 rows
Recorded power
37 hp
Recorded weight
1809 kg
Transmissions
Hydro-mechanical CVT.
Production years
2012-2015
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Cab standard with air-conditioning.Reference
Variants
KL37ZwheeledReference
KL37Z-PChalf-trackReference
Engine
Kubota 2.2L 4-cyl dieselReference
Fuel tank39.0 LReference
Engine27.2 kWReference
Kubota V2203Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke87 x 92 mmReference
Power27.2 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Fuel TypedieselReference
No of Cylinders4 cylinderReference
Rated engine speed2,600 rpmReference
Bore and stroke3.43x3.64 inchesReference
Cooling systemliquid-cooledReference
Transmission
continuously-varaible transmissionReference
TransmissionDual DriveReference
Typecontinuously-varaible transmissionReference
Gearsinfinite forward and reverse (2-range)Reference
Clutchdry discReference
Hydro-mechanical CVT.Reference
Gearsinfinite forward and reverse (3-range)Reference
Transmission TypeCVTReference
Wheel Drive4WDReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM546@2600Reference
Engine RPM773@2600Reference
Engine RPM969@2600Reference
Engine RPM1296@2600Reference
Engine RPM-770@2600Reference
Dimensions
Wheelbase188 cmReference
Weight1809 kgReference
Front tire8-18Reference
Rear tire12.4-28Reference
Standard tires (ag)Front: 8-18. Rear: 12.4-28Reference
Length338 cmReference
Width152 cmReference
Height (cab)228 cmReference
Ground clearance40 cmReference
Front tread119 cmReference
Rear tread120 to 143 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Capacities
Capacity134.1 ciReference
Power
Max Power36.5 hpReference
PTO
Rear PTO PowerAvailableReference
Rear PTO RPM540 RPMReference
Engine Speed on Rear PTO speed1,296@2,600 rpmReference
