Tractor · 2012Unverified
Kubota KL37Z-PC
Kubota KL37Z-PC — KL Kingwel Zero Series · 37 hp. Reference specifications; pending source verification.
The Kubota KL37Z-PC is a tractor with a rating of 37 hp, positioned at the lighter end of its class. This model was in production from 2012 to 2015, featuring a 4-cylinder diesel liquid-cooled engine. It has a tracked undercarriage with a continuously variable transmission, and its operating weight is 2075 kg. The KL37Z-PC is suitable for operations on up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Weight
2075 kg
Catalogue coverage
Variants represented
2
Richest spec table
48 rows
Recorded power
37 hp
Recorded weight
2075 kg
Transmissions
Hydro-mechanical CVT.
Production years
2012-2015
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Mechanical wet disc brakesReference
Cab standard with air-conditioning.Reference
Variants
KL37ZwheeledReference
KL37Z-PChalf-trackReference
Engine
Kubota 2.2L 4-cyl dieselReference
Fuel tank39.0 LReference
Engine27.2 kWReference
Kubota V2203Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke87 x 92 mmReference
Power27.2 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
continuously-varaible transmissionReference
TransmissionDual DriveReference
Typecontinuously-varaible transmissionReference
Gearsinfinite forward and reverse (3-range)Reference
Clutchdry discReference
Hydro-mechanical CVT.Reference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM546@2600Reference
Engine RPM773@2600Reference
Engine RPM969@2600Reference
Engine RPM1298@2600Reference
Engine RPM-770@2600Reference
Dimensions
Wheelbase188 cmReference
Weight2075 kgReference
Front tire8-18Reference
Rear tiretracksReference
Ag front8-18Reference
Ag rear400mm trackReference
Length339 cmReference
Width167 cmReference
Height (cab)231 cmReference
Ground clearance42 cmReference
Front tread119 cmReference
Rear tread127 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
