Tractor · 1999Unverified

Kubota KL41 Hi-Speed

Name: Kubota KL41 Hi-Speed
Brand: Kubota

Kubota KL41 Hi-Speed — KL Series · 41 hp. Reference specifications; pending source verification.

The Kubota KL41 Hi-Speed is a tractor model with a rated power of 41 hp, positioning it at the lighter end of its class. It was manufactured between 1999 and 2005 and features a 4-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a 20-speed gearbox. The tractor's operating weight ranges from 3351 to 3748 pounds, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

41 hp

Weight

3351 to 3748 pounds

Catalogue coverage

Variants represented

Richest spec table

48 rows

Recorded power

41 hp

Recorded weight

1520 kg

Transmissions

20-speed

Production years

1999-2005

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post ROPS. Cab optional.Reference

Engine

Kubota 2.2L 4-cyl dieselReference

Fuel tank40.1 LReference

Engine30.9 kWReference

Kubota V2203Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.2 LReference

Bore/Stroke87 x 92 mmReference

Power30.9 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

20-speedReference

30-speedReference

Gears20 forward and reverseReference

Four gears (1-4) in two ranges with three-range shift (creeper, medium, and high-speed).Reference

Gears30 forward and 20 reverseReference

Twelve gears in three ranges (creeper, medium, and high-speed) with shuttle shift. Only gears 1-8 available in reverse. In high-speed range only gears six forward and four reverse gears available.Reference

PTO & Hydraulics

Rear TypeIReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2600Reference

Engine RPM762@2600Reference

Engine RPM944@2600Reference

Engine RPM1258@2600Reference

Engine RPM-944@2600Reference

Dimensions

Wheelbase188 cmReference

Weight3351 to 3748 poundsReference

Front tire8-18Reference

Rear tire13.6-26Reference

Standard tires (ag)Front: 8-18. Rear: 13.6-26Reference

Length344 cmReference

Width149 cmReference

Height (ROPS)231 cmReference

Height (cab)215 cmReference

ROPS Weight1520 kgReference

Cab Weight1700 kgReference

Ground clearance40 cmReference

Front tread119 cmReference

Rear tread114 to 143 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
