Tractor · 2008Unverified
Kubota KL415 Hi-Speed
Kubota KL415 Hi-Speed — KL Series · 41 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
41 hp
Weight
3395 to 3836 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Variants
KL415standardReference
KL415Hhigh-speedReference
Engine
Kubota 2.2L 4-cyl dieselReference
Fuel tank40.1 LReference
Engine30.9 kWReference
Kubota V2203Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke87 x 92 mmReference
Power30.9 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
30-speedReference
Gears30 forward and 20 reverseReference
Twelve gears in three ranges (creeper, medium, and high-speed) with shuttle shift. Only gears 1-8 available in reverse. In high-speed range only gears six forward and four reverse gears available.Reference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2600Reference
Engine RPM762@2600Reference
Engine RPM944@2600Reference
Engine RPM1258@2600Reference
Engine RPM-944@2600Reference
Dimensions
Wheelbase188 cmReference
Weight3395 to 3836 poundsReference
Front tire8-18Reference
Rear tire13.6-26Reference
Standard tires (ag)Front: 8-18. Rear: 13.6-26Reference
Length344 cmReference
Width149 cmReference
Height (ROPS)231 cmReference
Height (cab)219 cmReference
ROPS Weight1539 kgReference
Cab Weight1740 kgReference
Ground clearance40 cmReference
Front tread119 cmReference
Rear tread114 to 143 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
