Tractor · 2006Unverified

Kubota KL430

Name: Kubota KL430
Brand: Kubota

Kubota KL430 — KL Series · 42 hp. Reference specifications; pending source verification.

The Kubota KL430 is a lightweight tractor model with a rated power output of 42 hp, positioning it at the lower end of its class. It was produced between 2006 and 2007. The tractor is equipped with a 3-cylinder diesel liquid-cooled engine, four-wheel drive and a 16-speed gearbox. Its operating weight ranges from 3329 to 3726 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

42 hp

Weight

3329 to 3726 pounds

Catalogue coverage

Variants represented

Richest spec table

48 rows

Recorded power

42 hp

Recorded weight

1510 kg

Transmissions

16-speed

Production years

2006-2007

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post ROPS. Cab optional.Reference

Engine

Kubota 1.5L 3-cyl dieselReference

Fuel tank40.1 LReference

Engine31.6 kWReference

Kubota D1503Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke83 x 92 mmReference

Power31.6 kWReference

Rated RPM2800Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speedReference

24-speedReference

Gears16 forward and reverseReference

Four gears (1-4) in two ranges with additional creeper range and shuttle shift.Reference

Gears24 forward and 16 reverseReference

Twelve gears in two ranges (creeper and high) with shuttle shift. Only eight gears available in reverse.Reference

PTO & Hydraulics

Rear TypeIReference

Rear PTO Type540 (1.375)Reference

Engine RPM553@2800Reference

Engine RPM779@2800Reference

Engine RPM966@2800Reference

Engine RPM1287@2800Reference

Engine RPM-966@2800Reference

Dimensions

Wheelbase191 cmReference

Weight3329 to 3726 poundsReference

Front tire8-18Reference

Rear tire13.6-26Reference

Standard tires (ag)Front: 8-18. Rear: 13.6-26Reference

Length346 cmReference

Width149 cmReference

Height (ROPS)198 cmReference

Height (cab)198 cmReference

ROPS Weight1510 kgReference

Cab Weight1690 kgReference

Ground clearance36 cmReference

Front tread118 cmReference

Rear tread114 to 143 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
