Tractor · 2010Unverified
Kubota KL4350-PC
Kubota KL4350-PC — KL Kingwel 50 Series · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
1945 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Mechanical wet disc brakesReference
Cab standard with air-conditioning.Reference
Variants
KL4350wheeledReference
KL4350-PChalf-trackReference
Engine
Kubota 2.4L 4-cyl dieselReference
Fuel tank48.1 LReference
Engine37.5 kWReference
Kubota V2403Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke87 x 102 mmReference
Power37.5 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speedReference
Gears24 forward and 16 reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM567@2700Reference
Engine RPM800@2700Reference
Engine RPM990@2700Reference
Engine RPM1321@2700Reference
Engine RPM-990@2700Reference
Dimensions
Wheelbase188 cmReference
Weight1945 kgReference
Front tire8-18Reference
Rear tiretracksReference
Ag front8-18Reference
Ag rear400mm tracksReference
Length344 cmReference
Width164 cmReference
Height (cab)223 cmReference
Ground clearance41 cmReference
Front tread119 cmReference
Rear tread122 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
