Tractor · 2006Unverified
Kubota KL460 Hi-Speed
Kubota KL460 Hi-Speed — KL Series · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
3583 to 3968 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Engine
Kubota 2.4L 4-cyl dieselReference
Fuel tank45.0 LReference
Engine33.8 kWReference
Kubota V2403Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke87 x 102 mmReference
Power33.8 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
20-speedReference
30-speedReference
Gears20 forward and reverseReference
Four gears (1-4) in two ranges with three-range shift (creeper, medium, and high-speed).Reference
Gears30 forward and 20 reverseReference
Twelve gears in three ranges (creeper, medium, and high-speed) with shuttle shift. Only gears 1-8 available in reverse. In high-speed range only gears six forward and four reverse gears available.Reference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM556@2600Reference
Engine RPM784@2600Reference
Engine RPM972@2600Reference
Engine RPM1295@2600Reference
Engine RPM-972@2600Reference
Dimensions
Wheelbase194 cmReference
Weight3583 to 3968 poundsReference
Front tire8.3-20Reference
Rear tire13.6-28Reference
Standard tires (ag)Front: 8.3-20. Rear: 13.6-28Reference
Length353 cmReference
Width153 cmReference
Height (ROPS)236 cmReference
Height (cab)219 cmReference
ROPS Weight1625 kgReference
Cab Weight1799 kgReference
Ground clearance43 cmReference
Front tread121 cmReference
Rear tread114 to 143 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
