Tractor · 2012Unverified

Kubota KL48Z-PC

Name: Kubota KL48Z-PC
Brand: Kubota

Kubota KL48Z-PC — KL Kingwel Zero Series · 47 hp. Reference specifications; pending source verification.

The Kubota KL48Z-PC is a tractor with a power rating of 47 hp, categorising it as one of the more compact options within its class. Manufactured between 2012 and 2015, this model features a 4-cylinder diesel liquid-cooled engine, which powers a tracked undercarriage coupled to a continuously variable transmission. The model's listed weight is 2145 kg, while its operational capacity is reportedly around 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

47 hp

Weight

2145 kg

Catalogue coverage

Variants represented

Richest spec table

51 rows

Recorded power

47 hp

Recorded weight

2145 kg

Transmissions

30-speed

Production years

2012-2015

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Half-track Crawler tractorReference

Drivehalf-trackReference

Power steeringReference

Mechanical wet disc brakesReference

Cab standard with air-conditioning.Reference

Variants

KL48ZwheeledReference

KL48Z-PChalf-trackReference

Engine

Kubota 2.4L 4-cyl dieselReference

Fuel tank48.1 LReference

Engine35.3 kWReference

Kubota V2403Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.4 LReference

Bore/Stroke87 x 102 mmReference

Power35.3 kWReference

Rated RPM2700Reference

StarterelectricReference

Starter volts12Reference

Transmission

continuously-varaible transmissionReference

30-speedReference

TransmissionDual DriveReference

Typecontinuously-varaible transmissionReference

Gearsinfinite forward and reverse (3-range)Reference

Clutchdry discReference

Hydro-mechanical CVT.Reference

Gears30 forward and 20 reverseReference

Three range transmission. Twelve forward, eight reverse, in creeper and medium range. Six forward, four reverse, in high-speed range.Reference

PTO & Hydraulics

Rear TypeIReference

Rear PTO Type540 (1.375)Reference

Engine RPM562@2700Reference

Engine RPM796@2700Reference

Engine RPM997@2700Reference

Engine RPM1336@2700Reference

Engine RPM-793@2700Reference

Dimensions

Wheelbase192 cmReference

Weight2145 kgReference

Front tire8.3-20Reference

Rear tiretracksReference

Ag front8.3-20Reference

Ag rear400mm trackReference

Length347 cmReference

Width167 cmReference

Height (cab)233 cmReference

Ground clearance44 cmReference

Front tread121 cmReference

Rear tread127 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
