Tractor · 2010Unverified
Kubota KL5150-PC
Kubota KL5150-PC — KL Kingwel 50 Series · 54 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
54 hp
Weight
3968 to 4398 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post ROPS. Cab optional with air-conditioning.Reference
Variants
KL5150wheeledReference
KL5150-PChalf-trackReference
Engine
Kubota 2.4L 4-cyl dieselReference
Fuel tank48.1 LReference
Engine40.5 kWReference
Kubota V2403Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke87 x 102 mmReference
Power40.5 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speedReference
Gears24 forward and 16 reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM567@2700Reference
Engine RPM800@2700Reference
Engine RPM990@2700Reference
Engine RPM1321@2700Reference
Engine RPM-990@2700Reference
Dimensions
Wheelbase192 cmReference
Weight3968 to 4398 poundsReference
Front tire8.3-20Reference
Rear tiretracksReference
Ag front8.3-20Reference
Ag rear400mm tracksReference
Length352 cmReference
Width164 cmReference
Height (ROPS)236 cmReference
Height (cab)228 cmReference
ROPS Weight1799 kgReference
Cab Weight1994 kgReference
Ground clearance43 cmReference
Front tread121 cmReference
Rear tread122 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
