Tractor · 2006Unverified
Kubota KL550 Hi-Speed
Kubota KL550 Hi-Speed — KL Series · 54 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
54 hp
Weight
1850 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Cab standard.Reference
Engine
Kubota 2.4L 4-cyl dieselReference
Fuel tank46.9 LReference
Engine40.5 kWReference
Kubota V2403Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke87 x 102 mmReference
Power40.5 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
30-speedReference
Gears30 forward and 20 reverseReference
Twelve gears in three ranges (creeper, medium, and high-speed) with shuttle shift. Only gears 1-8 available in reverse. In high-speed range only gears six forward and four reverse gears available.Reference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM545@2700Reference
Engine RPM769@2700Reference
Engine RPM952@2700Reference
Engine RPM1270@2700Reference
Engine RPM-952@2700Reference
Dimensions
Wheelbase194 cmReference
Weight1850 kgReference
Front tire8.3-20Reference
Rear tire12.4-32Reference
Standard tires (ag)Front: 8.3-20. Rear: 12.4-32Reference
Length355 cmReference
Width153 cmReference
Height (cab)221 cmReference
Ground clearance43 cmReference
Front tread121 cmReference
Rear tread113 to 152 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
