Tractor · 2005Unverified

Kubota KT210

Name: Kubota KT210
Brand: Kubota

Kubota KT210 — KT Kingeye Series · 21 hp. Reference specifications; pending source verification.

The Kubota KT210 is a compact tractor model rated at 21 hp. It was produced from 2005 to 2008. The tractor features a 3-cylinder diesel liquid-cooled engine, which powers a four-wheel drive system via a powershift transmission. Its listed weight ranges from 1984 to 2293 pounds, with an operating capacity of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

21 hp

Weight

1984 to 2293 pounds

Catalogue coverage

Variants represented

Richest spec table

53 rows

Recorded power

21 hp

Transmissions

12-speed

Production years

2005-2008

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional with air-conditioning.Reference

Engine

Kubota 1.4L 3-cyl dieselReference

Fuel tank28.0 LReference

Engine15.4 kWReference

Kubota D1403Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.4 LReference

Bore/Stroke79 x 91 mmReference

Power15.4 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speedReference

48-speed power shiftReference

ROPS gear899 kgReference

Cab gear1020 kgReference

Gears12 forward and reverseReference

Clutchdry discReference

Three gears (1-3) in four ranges (creeper, low, medium, high) with shuttle shift.Reference

TransmissionGlideshiftReference

Typepower shiftReference

Gears48 forward and 30 reverseReference

Sixteen gears (10 in reverse) with three ranges. Gears may be shifted sequentially while moving, without using the clutch. Tractor must be stopped, and clutch used, to shift ranges.Reference

PTO & Hydraulics

Rear TypeIReference

Rear PTO Type540 (1.375)Reference

Engine RPM554@2600Reference

Engine RPM802@2600Reference

Engine RPM1182@2600Reference

Engine RPM-675@2600Reference

Dimensions

Wheelbase150 cmReference

Weight1984 to 2293 poundsReference

Front tire6-14Reference

Rear tire8.3-24Reference

Standard tires (ag)Front: 6-14. Rear: 8.3-24Reference

Optional tires (ag)Front: 6-14. Rear: 9.5-22Reference

Length283 cmReference

Width117 cmReference

Height (ROPS)190 cmReference

Height (cab)193 cmReference

Ground clearance32 cmReference

Front tread97 cmReference

Rear tread94/106 cmReference

ROPS Glideshift919 kgReference

Cab Glideshift1040 kgReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
