Tractor · 2005Unverified
Kubota KT300
Kubota KT300 — KT Kingeye Series · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
2216 to 2535 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Engine
Kubota 1.5L 3-cyl dieselReference
Fuel tank28.0 LReference
Engine22.1 kWReference
Kubota D1503Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke83 x 92 mmReference
Power22.1 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
48-speed power shiftReference
ROPS gear1005 kgReference
Cab gear1129 kgReference
Gears12 forward and reverseReference
Clutchdry discReference
Three gears (1-3) in four ranges (creeper, low, medium, high) with shuttle shift.Reference
TransmissionGlideshiftReference
Typepower shiftReference
Gears48 forward and 30 reverseReference
Sixteen gears (10 in reverse) with three ranges. Gears may be shifted sequentially while moving, without using the clutch. Tractor must be stopped, and clutch used, to shift ranges.Reference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM545@2700Reference
Engine RPM789@2700Reference
Engine RPM1227@2700Reference
Engine RPM-664@2700Reference
Dimensions
Wheelbase150 cmReference
Weight2216 to 2535 poundsReference
Front tire7-16Reference
Rear tire11.2-26Reference
Standard tires (ag)Front: 7-16. Rear: 11.2-26Reference
ROPS Length289 cmReference
Cab Length286 cmReference
Width132 cmReference
Height (ROPS)196 cmReference
Height (cab)201 cmReference
Ground clearance37 cmReference
Front tread105 cmReference
Rear tread104 cmReference
ROPS Glideshift1025 kgReference
Cab Glideshift1149 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
