Tractor · 1988Unverified

Kubota L1-315

Name: Kubota L1-315
Brand: Kubota

Kubota L1-315 — L1 Series · 28 hp. Reference specifications; pending source verification.

The Kubota L1-315 is a compact tractor with a rating of 28 hp. Manufactured from 1988 to 1991, it features a 4-cylinder diesel liquid-cooled engine and four-wheel drive, coupled with a 16-speed gearbox. The tractor's weight is listed as 2546 to 2712 pounds. It is designed for use on land areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

28 hp

Weight

2546 to 2712 pounds

Catalogue coverage

Variants represented

Richest spec table

41 rows

Recorded power

28 hp

Recorded weight

1154 kg

Transmissions

16-speed

Production years

1988-1991

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Two- or four-wheel driveReference

Open operator station.Reference

Engine

Kubota 1.5L 4-cyl dieselReference

Engine22.4 kWReference

Kubota V1512Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Power22.4 kWReference

Rated RPM2800Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speedReference

Gears16 forward and reverseReference

PTO & Hydraulics

PTO (claimed)21.0 kWReference

Pump flow24.2 lpmReference

Rear TypeIReference

Rear lift694 kgReference

Rear PTO Type622/867/1077/1400 (1.375)Reference

Dimensions

Wheelbase173 cmReference

Weight2546 to 2712 poundsReference

Front tire5.00-15Reference

2WD Rear tire13.6-24Reference

2WD Standard tires (ag)Front: 5.00-15. Rear: 13.6-24Reference

4WD Standard tires (ag)Front: 8-16. Rear: 13.6-24Reference

Length315 cmReference

Width141 cmReference

2WD Height143 cmReference

4WD Height144 cmReference

2WD Weight1154 kgReference

4WD Weight1230 kgReference

2WD Ground clearance36 cmReference

4WD Ground clearance34 cmReference

2WD Front tread104 to 145 cmReference

4WD Front tread108 cmReference

Rear tread107 to 154 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
