Tractor · 1987Unverified

Kubota L1-435

Name: Kubota L1-435
Brand: Kubota

Kubota L1-435 — L1 Series · 41 hp. Reference specifications; pending source verification.

The Kubota L1-435 is a compact tractor with a rated output of 41 hp. Produced from 1987 to 1991, this model features a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, transmitting power through a 16-speed gearbox to four-wheel drive. It has a listed weight range of 3153 to 3340 pounds. The Kubota L1-435 is designed for tasks typically covering areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

41 hp

Weight

3153 to 3340 pounds

Catalogue coverage

Variants represented

Richest spec table

47 rows

Recorded power

41 hp

Recorded weight

1430 kg

Transmissions

16-speed

Production years

1987-1991

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Two- or four-wheel driveReference

Open operator station.Reference

Variants

L1-435DFour-wheel driveReference

Engine

Kubota 1.5L 4-cyl dieselReference

Fuel tank46.2 LReference

Engine32.1 kWReference

Kubota V1512Reference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooled inlineReference

Displacement1.5 LReference

Bore/Stroke76 x 82 mmReference

Power32.1 kWReference

Rated RPM2700Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speedReference

Gears16 forward and reverseReference

Four gears in four ranges with shuttle shift.Reference

PTO & Hydraulics

PTO (claimed)30.9 kWReference

Rear TypeJIS1Reference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM545@2700Reference

Engine RPM942@2700Reference

Engine RPM913@2700Reference

Engine RPM1242@2700Reference

Dimensions

Wheelbase184 cmReference

Weight3153 to 3340 poundsReference

Front tire6.00-16Reference

2WD Rear tire13.6-26Reference

2WD Standard tires (ag)Front: 6.00-16. Rear: 13.6-26Reference

4WD Standard tires (ag)Front: 8-18. Rear: 13.6-26Reference

Length345 cmReference

Width148 cmReference

Height (exhaust)197 cmReference

2WD Weight1430 kgReference

4WD Weight1515 kgReference

2WD Ground clearance37 cmReference

4WD Ground clearance33 cmReference

2WD Front tread114 to 146 cmReference

4WD Front tread119 cmReference

Rear tread114 to 152 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
