Tractor · 1989Unverified
Kubota L2050
Kubota L2050 — L Series · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
1781 to 2094 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Two- or four-wheel driveReference
2WD SteeringmanualReference
4WD SteeringpowerReference
Wet disc brakesReference
Two-post ROPS.Reference
Variants
L2050F2WDReference
L2050DT4WDReference
Engine
Kubota 1.1L 3-cyl dieselReference
Fuel tank29.1 LReference
Engine (gross)18.6 kWReference
Kubota D1102-AReference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.1 LReference
Bore/Stroke76 x 82 mmReference
Power (gross)18.6 kWReference
Rated RPM2800Reference
Starter volts12Reference
Oil capacity6.3 LReference
Coolant capacity6.0 LReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
Four gears, plus reverse, in two ranges.Reference
PTO & Hydraulics
PTO (claimed)14.9 kWReference
Typeopen centerReference
Pump flow16.7 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift850 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Front PTO Type2800Reference
Dimensions
2WD Wheelbase155 cmReference
4WD Wheelbase156 cmReference
Weight1781 to 2094 poundsReference
Front tire4.00-15Reference
4WD Rear tire9.5-24Reference
Weight180 kgReference
4WD Standard tires (ag)Front: 4.00-15. Rear: 9.5-24Reference
4WD Standard tires (ag)Front: 6-14. Rear: 9.5-24Reference
2WD Optional tires (ag)Front: 5.00-15. Rear: 11.2-24Reference
4WD Optional tires (ag)Front: 7-16. Rear: 11.2-24Reference
2WD Lawn/turf front23x8.50-12Reference
4WD Lawn/turf front24x8.50-14Reference
Lawn/turf rear13.6-16Reference
Length263 cmReference
Width127 cmReference
Height193 cmReference
2WD Shipping weight807 kgReference
4WD Shipping weight949 kgReference
Ground clearance34 cmReference
Front tread101 cmReference
Rear tread103 cmReference
Kubota L2050 attachments
60" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
Kubota BF400S loaderReference
Kubota LB400 loaderReference
Kubota LA450S loaderReference
BackhoeReference
60" Mower deck
Typemid-mount Kubota RC60-20Reference
Type3-bladeReference
Cutting width152 cmReference
Overall width183 cmReference
Cut height3 to 10 cmReference
Kubota BL4590 Backhoe
Backhoe typeKubota BL4590 BackhoeReference
Transport height200 cmReference
Bucket width33 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Bucket width76 cmReference
Bucket width91 cmReference
Digging depth229 cmReference
Reach from pivot295 cmReference
Loading height200 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1338 kgReference
Dipperstick force789 kgReference
Kubota BL4690 Backhoe
Backhoe typeKubota BL4690 BackhoeReference
Transport height195 cmReference
Bucket width25 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width60 cmReference
Digging depth229 cmReference
Reach from pivot295 cmReference
Loading height191 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1338 kgReference
Dipperstick force789 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
