Tractor · 1989Unverified

Kubota L2050

Name: Kubota L2050
Brand: Kubota

Kubota L2050 — L Series · 25 hp. Reference specifications; pending source verification.

The Kubota L2050 is a tractor model with a rated power output of 25 horsepower, positioning it at the lighter end of its class. It was manufactured from 1989 to 1991. The tractor features a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive and an 8-speed gearbox. It has an operating weight of between 1781 and 2094 pounds, suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

25 hp

Weight

1781 to 2094 pounds

Catalogue coverage

Variants represented

Richest spec table

99 rows

Recorded power

25 hp

Transmissions

8-speed gear

Production years

1989-1991

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Two- or four-wheel driveReference

2WD SteeringmanualReference

4WD SteeringpowerReference

Wet disc brakesReference

Two-post ROPS.Reference

Variants

L2050F2WDReference

L2050DT4WDReference

Engine

Kubota 1.1L 3-cyl dieselReference

Fuel tank29.1 LReference

Engine (gross)18.6 kWReference

Kubota D1102-AReference

dieselReference

3-cylinderReference

liquid-cooled inlineReference

Displacement1.1 LReference

Bore/Stroke76 x 82 mmReference

Power (gross)18.6 kWReference

Rated RPM2800Reference

Starter volts12Reference

Oil capacity6.3 LReference

Coolant capacity6.0 LReference

Transmission

8-speed gearReference

TypegearReference

Gears8 forward and 2 reverseReference

Four gears, plus reverse, in two ranges.Reference

PTO & Hydraulics

PTO (claimed)14.9 kWReference

Typeopen centerReference

Pump flow16.7 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift850 kgReference

Rear PTOliveReference

Rear PTO Type540 (1.375)Reference

Front PTO Type2800Reference

Dimensions

2WD Wheelbase155 cmReference

4WD Wheelbase156 cmReference

Weight1781 to 2094 poundsReference

Front tire4.00-15Reference

4WD Rear tire9.5-24Reference

Weight180 kgReference

4WD Standard tires (ag)Front: 4.00-15. Rear: 9.5-24Reference

4WD Standard tires (ag)Front: 6-14. Rear: 9.5-24Reference

2WD Optional tires (ag)Front: 5.00-15. Rear: 11.2-24Reference

4WD Optional tires (ag)Front: 7-16. Rear: 11.2-24Reference

2WD Lawn/turf front23x8.50-12Reference

4WD Lawn/turf front24x8.50-14Reference

Lawn/turf rear13.6-16Reference

Length263 cmReference

Width127 cmReference

Height193 cmReference

2WD Shipping weight807 kgReference

4WD Shipping weight949 kgReference

Ground clearance34 cmReference

Front tread101 cmReference

Rear tread103 cmReference

Kubota L2050 attachments

60" mid-mount mower deckReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

60" mid-mount mower deckReference

Kubota BF400S loaderReference

Kubota LB400 loaderReference

Kubota LA450S loaderReference

BackhoeReference

60" Mower deck

Typemid-mount Kubota RC60-20Reference

Type3-bladeReference

Cutting width152 cmReference

Overall width183 cmReference

Cut height3 to 10 cmReference

Kubota BL4590 Backhoe

Backhoe typeKubota BL4590 BackhoeReference

Transport height200 cmReference

Bucket width33 cmReference

Bucket width45 cmReference

Bucket width60 cmReference

Bucket width76 cmReference

Bucket width91 cmReference

Digging depth229 cmReference

Reach from pivot295 cmReference

Loading height200 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force1338 kgReference

Dipperstick force789 kgReference

Kubota BL4690 Backhoe

Backhoe typeKubota BL4690 BackhoeReference

Transport height195 cmReference

Bucket width25 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width60 cmReference

Digging depth229 cmReference

Reach from pivot295 cmReference

Loading height191 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force1338 kgReference

Dipperstick force789 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
