The Kubota L2200 is a tractor with a rated power of 22 hp, positioning it at the lighter end of its class. It was manufactured from 1971 to 1975. The L2200 features a 3-cylinder diesel liquid-cooled engine, coupled with four-wheel drive and an 8-speed gearbox. It is designed for use on operations up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Catalogue coverage
Variants represented
2
Richest spec table
24 rows
Recorded power
22 hp
Transmissions
8-speed gear
Production years
1971-1975
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
L2200DT4WDReference
Engine
Kubota 1.1L 3-cyl dieselReference
Engine16.2 kWReference
Kubota DH1100Reference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.1 LReference
Bore/Stroke76 x 82 mmReference
Power16.2 kWReference
Rated RPM3000Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Rear PTO Type540 (1.375)Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
