Tractor · 1991Unverified
Kubota L2350
Kubota L2350 — L50 Series · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
1962 to 2205 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS.Reference
Variants
L2350F2WDReference
L2350DT4WDReference
Engine
Kubota 1.1L 3-cyl dieselReference
Engine (gross)18.6 kWReference
KubotaReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke76 x 81 mmReference
Power (gross)18.6 kWReference
Rated RPM2500Reference
Starter volts12Reference
Coolant capacity23.8 LReference
Transmission
8-speed constant meshReference
Typeconstant meshReference
Gears8 forward and 2 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)15.3 kWReference
Hydraulic system28.0 LReference
Typeopen centerReference
Capacity28.0 LReference
Pump flow16.7 lpmReference
Rear TypeIReference
Rear lift650 kgReference
Rear PTOliveReference
Rear PTO Type540Reference
Capacities
Fuel29.1 LReference
Dimensions
Wheelbase156 cmReference
Weight1962 to 2205 poundsReference
Front tire4.00-15Reference
2WD Rear tire9.5-24Reference
Weight180 kgReference
2WD Standard tires (ag)Front: 4.00-15. Rear: 9.5-24Reference
4WD Standard tires (ag)Front: 6-14. Rear: 9.5-24Reference
Length263 cmReference
Width127 cmReference
Height (ROPS)211 cmReference
2WD Weight889 kgReference
4WD Weight1000 kgReference
2WD Ground clearance34 cmReference
4WD Ground clearance30 cmReference
Front tread101 cmReference
Rear tread103 cmReference
Kubota L2350 attachments
60" mid-mount mower deckReference
front-end loaderReference
backhoeReference
L2350 Serial Number Location
Serial number plate on the left side of the L2350 tractor frame, above the front axle.Reference
L2350 Serial Numbers
1991unknownReference
199251460 (L2350DT)Reference
199352900 (L2350DT)Reference
199455760 (L2350DT)Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
Kubota LB400 loaderReference
Kubota LA450S loaderReference
BackhoeReference
60" Mower deck
Typemid-mount Kubota RC60-20Reference
Type3-bladeReference
Cutting width152 cmReference
Overall width183 cmReference
Cut height3 to 10 cmReference
Kubota BL4590 Backhoe
Backhoe typeKubota BL4590 BackhoeReference
Transport height200 cmReference
Bucket width33 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Bucket width76 cmReference
Bucket width91 cmReference
Digging depth229 cmReference
Reach from pivot295 cmReference
Loading height200 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1338 kgReference
Dipperstick force789 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
