Tractor · 2014Unverified
Kubota L2501
Kubota L2501 — L01 Standard Series · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
2425 to 2623 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WDReference
SteeringpowerReference
Mechanical wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Kubota 1.6L 3-cyl dieselReference
Fuel tank37.9 LReference
Engine (gross)18.5 kWReference
Engine (net)17.8 kWReference
KubotaReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke86 x 91 mmReference
EmissionsTier IVReference
Power (net)17.8 kWReference
Power (gross)18.5 kWReference
Fuel systemdirect injectionReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed gearReference
hydrostaticReference
2WD Gear1099 kgReference
4WD Gear1179 kgReference
TypegearReference
Gears8 forward and 4 reverseReference
Clutchdry discReference
Four gears (1-4) in two forward ranges (low/high) plus reverse.Reference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Gear PTO (claimed)15.3 kWReference
Hydro PTO (claimed)14.2 kWReference
Typeopen centerReference
Pressure152.0 barReference
Pump flow19.5 lpmReference
Steering flow11.8 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)870 kgReference
Rear lift (at 24"/610mm)630 kgReference
Rear PTOtransmissionReference
Rear PTOliveReference
Clutchoverrunning dry discReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase160 cmReference
Weight2425 to 2623 poundsReference
Front tire5-15Reference
Rear tire11.2-24 (2WD)Reference
Standard tires (ag)Front: 5-15. Rear: 11.2-24 (2WD)Reference
Standard tires (ag)Front: 7.2-16. Rear: 11.2-24 (4WD)Reference
Industrial front27x8.50-15 (4WD)Reference
Industrial rear15-19.5 (4WD)Reference
2WD Length280 cmReference
4WD Length270 cmReference
Width139 cmReference
Height (ROPS)232 cmReference
2WD Ground clearance34 cmReference
4WD Ground clearance34 cmReference
Front tread104 cmReference
Front tread109 cmReference
Rear tread111/119/129 cmReference
4WD Hydro1189 kgReference
Kubota L2501 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Charging volts12Reference
Battery CCA490Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Kubota BH77 Backhoe
Backhoe typeKubota BH77 BackhoeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
