Tractor · 2000Unverified

Kubota L2600

Name: Kubota L2600
Brand: Kubota

Kubota L2600 — Standard L Series · 27 hp. Reference specifications; pending source verification.

The Kubota L2600 is a tractor with a rated power output of 27 hp, positioning it at the lower end of its class. This model was manufactured between 2000 and 2003. Key features of the L2600 include a 3-cylinder diesel liquid-cooled engine and a four-wheel drive system paired with an 8-speed gearbox. Its operating weight ranges from 2116 to 2359 pounds, with a capacity for operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

27 hp

Weight

2116 to 2359 pounds

Catalogue coverage

Variants represented

Richest spec table

80 rows

Recorded power

27 hp

Recorded weight

959 kg

Transmissions

8-speed sliding gear

Production years

2000-2003

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Two- or four-wheel driveReference

Differential lockmechanical rearReference

2WD SteeringmanualReference

4WD SteeringpowerReference

Wet disc brakesReference

Two-post ROPS.Reference

Variants

L2600F2WDReference

L2600DT4WDReference

Engine

Kubota 1.4L 3-cyl dieselReference

Fuel tank31.0 LReference

Engine (gross)20.1 kWReference

Kubota D1403Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.4 LReference

Bore/Stroke79 x 91 mmReference

Power (gross)20.1 kWReference

Fuel systemindirect injectionReference

Rated RPM2800Reference

Torque78.0 NmReference

Starter volts12Reference

Oil capacity5.5 LReference

Coolant capacity6.0 LReference

Transmission

8-speed sliding gearReference

Typesliding gearReference

Gears8 forward and 2 reverseReference

Clutchdry discReference

Unsynchronized transmission. Tractor must be stopped to shift gears.Reference

PTO & Hydraulics

PTO (claimed)16.8 kWReference

Typeopen centerReference

2WD Total flow17.4 lpmReference

4WD Total flow27.3 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)900 kgReference

Rear PTOtransmissionReference

Clutchoverrunning dry discReference

Rear PTO Type540 (1.375)Reference

Dimensions

2WD Wheelbase155 cmReference

4WD Wheelbase156 cmReference

Weight2116 to 2359 poundsReference

Front tire5.00-15Reference

Rear tire11.2-24Reference

Ag front5.00-15 (2WD)Reference

Ag front7-16 (4WD)Reference

Ag rear11.2-24Reference

2WD Length266 cmReference

4WD Length264 cmReference

Width129 cmReference

Height211 cmReference

2WD Weight959 kgReference

4WD Weight1070 kgReference

2WD Ground clearance34 cmReference

4WD Ground clearance30 cmReference

Kubota L2600 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery CCA490Reference

Battery volts12Reference

Attachment overview

Kubota LB400 loaderReference

Kubota LB402 loaderReference

Kubota LB452S loaderReference

BackhoeReference

The Kubota L2600 was advertised with the RCR60CA (60-inch) or RCR72CA (72-inch) rear-mount mowers.Reference

Kubota BL4690A Backhoe

Backhoe typeKubota BL4690A BackhoeReference

Transport height195 cmReference

Bucket width25 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width60 cmReference

Digging depth229 cmReference

Reach from pivot295 cmReference

Loading height191 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force1338 kgReference

Dipperstick force789 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
