Tractor · 1976Unverified
Kubota L2601
Kubota L2601 — L01 Series · 26 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Weight
1015 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Built in JapanReference
Two- or four-wheel driveReference
Open operator station.Reference
Variants
L26012WDReference
L2601DT4WDReference
Engine
Kubota 1.3L 3-cyl dieselReference
Fuel tank35.0 LReference
Engine19.1 kWReference
Kubota D1301Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke82 x 82 mmReference
Power19.1 kWReference
Rated RPM2800Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed gearReference
TypegearReference
Gears16 forward and 4 reverseReference
PTO & Hydraulics
Rear TypeJIS1Reference
Rear PTO Type540 (1.375)Reference
Engine RPM622@2800Reference
Engine RPM809@2800Reference
Engine RPM1161@2800Reference
Engine RPM1400@2800Reference
Dimensions
Wheelbase165 cmReference
Weight1015 kgReference
Front tire5.00-15Reference
Rear tire11.2/10-24Reference
Standard tires (ag)Front: 5.00-15. Rear: 11.2/10-24Reference
Length284 cmReference
Width130 cmReference
Height (steering wheel)140 cmReference
Height (exhaust)189 cmReference
Ground clearance34 cmReference
L2601 Serial Number Location
Serial number plate on the left side of the L2601 tractor frame, just ahead of the clutch pedal.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
