Tractor · 1981Unverified
Kubota L275
Kubota L275 — L Series · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Max power
13.8 kW
Weight
1179 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Built in JapanReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (L275DT)Reference
SteeringmanualReference
Steeringpower assist optionalReference
Differential mechanical wet disc brakesReference
Two-post ROPS.Reference
Variants
L2752WDReference
L275DT4WDReference
Engine
Kubota 1.3L 3-cyl dieselReference
Fuel tank28.0 LReference
Engine (gross)20.5 kWReference
Drawbar (tested)13.8 kWReference
Kubota D1302-AReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke82 x 82 mmReference
Power (gross)20.5 kWReference
Air cleanerpaper elementReference
Compression21:1Reference
Rated RPM2600Reference
Starter volts12Reference
Power at rated engine speed17.5 kWReference
Max power13.8 kWReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 7 reverseReference
Clutchdry discReference
Four gears in two ranges with forward/reverse shuttle.Reference
PTO & Hydraulics
PTO (claimed)17.2 kWReference
PTO (tested)17.5 kWReference
Typeopen centerReference
Pump flow23.5 lpmReference
Rear TypeIReference
Rear PTOliveReference
Rear PTO Type540Reference
Power at rated PTO speed17.2 kWReference
Dimensions
Wheelbase168 cmReference
Wheelbase164 cmReference
Weight1179 kgReference
Front tire5.00-15Reference
Rear tire11.2-24Reference
Ag front5.00-15 (2WD)Reference
Ag front7-16 (4WD)Reference
Ag rear11.2-24Reference
Lawn/turf front23x8.50-12 (2WD)Reference
Lawn/turf front27x8.50-16 (4WD)Reference
Lawn/turf rear13.6-16Reference
Length286 cmReference
Width139 cmReference
Height (exhaust)198 cmReference
Operating weight1179 kgReference
Ground clearance36 cmReference
Ground clearance30 cmReference
Kubota L275 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Kubota BL4520 Backhoe
Backhoe typeKubota BL4520 BackhoeReference
Transport height155 cmReference
Bucket width25 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
2-Foot flat digging depth201 cmReference
Reach from pivot248 cmReference
Loading height213 cmReference
Bucket Rotation170°Reference
Swing Arc177°Reference
Bucket force657 kgReference
Dipperstick force1308 kgReference
Kubota L4530 Backhoe
Backhoe typeKubota L4530 BackhoeReference
Transport height186 cmReference
Bucket width25 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
2-Foot flat digging depth215 cmReference
Reach from pivot279 cmReference
Loading height185 cmReference
Bucket Rotation164°Reference
Swing Arc180°Reference
Bucket force746 kgReference
Dipperstick force1310 kgReference
Test results
Diesel 8-speed 4WDSeptember 17 - October 2, 1981Link: Nebraska Tractor Test 1407 fileReference
PTO performanceReference
Fuel use6.1 l/hourReference
Drawbar performanceReference
Gear 6 used for power test.Reference
Max pull1497 kgReference
Gear 3 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
