Tractor · 2004Unverified

Kubota L2800

Name: Kubota L2800
Brand: Kubota

Kubota L2800 — Model year 2004-20072008-2010 · 29 hp. Reference specifications; pending source verification.

The Kubota L2800 is a tractor with an approximate engine power output of 29 hp, categorising it as a lighter tractor in its class. Manufactured from 2004 to 2010, the L2800 is equipped with a 3-cylinder diesel liquid-cooled engine and a four-wheel drive system featuring a hydrostatic transmission. Its operational weight ranges from 2359 to 2600 pounds. The tractor is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

29 hp

Max power

29 hp

Weight

2359 to 2600 pounds

Catalogue coverage

Variants represented

Richest spec table

127 rows

Recorded power

29 hp

Transmissions

hydrostatic

Production years

2004-2010

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Two- or four-wheel driveReference

Differential lockrear standardReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post ROPS. Foldable ROPS optional.Reference

Variants

L2800F2WD gearReference

L2800DT4WD gearReference

L2800HST4WD hydroReference

Engine

Kubota 1.4L 3-cyl dieselReference

Engine (gross)21.6 kWReference

Kubota D1403Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Original engine. Used in the L2800 from 2004 until the 2008 model year.Reference

Displacement1.4 LReference

Bore/Stroke80 x 92 mmReference

EmissionsTier IIReference

Power (gross)21.6 kWReference

Rated RPM2800Reference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders3 CylinderReference

Rated engine speed2,800 RPMReference

Emissions complianceTier IIReference

Bore and stroke3.15x3.638 inchesReference

Cooling systemliquid-cooledReference

Transmission

hydrostaticReference

8-speedReference

2WD gear1070 kgReference

4WD gear1150 kgReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Transmissionconstant meshReference

Gears8 forward and 4 reverseReference

ClutchdryReference

Oil capacity27.6 LReference

Four gears (1-4) in two ranges (Low/High) and reverse (R). Mechanical shuttle shifting between forward-low and reverse.Reference

Transmission TypeHSTReference

Wheel Drive4WDReference

PTO & Hydraulics

Gear PTO (claimed)17.9 kWReference

Hydro PTO (claimed)16.8 kWReference

Hydraulic system27.6 LReference

Typeopen centerReference

Capacity27.6 LReference

Valves0 to 3Reference

Pump flow25.7 lpmReference

Total flow42.0 lpmReference

Steering flow16.3 lpmReference

Rear TypeIReference

Rear lift (at ends)900 kgReference

Rear lift (at 24"/610mm)650 kgReference

Rear PTOtransmissionReference

Hydro Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2430Reference

Capacities

Fuel34.1 LReference

Front axle4.5 LReference

Fuel tank34.1 LReference

Dimensions

2WD Wheelbase161 cmReference

4WD Wheelbase160 cmReference

Weight2359 to 2600 poundsReference

Front tire5-15Reference

2WD Rear tire11.2-24Reference

2WD Standard tires (ag)Front: 5-15. Rear: 11.2-24Reference

4WD Standard tires (ag)Front: 7-16. Rear: 11.2-24Reference

Lawn/turf front23x8.50-12Reference

4WD Lawn/turf front25x8.50-14Reference

Lawn/turf rear13.6-16Reference

Industrial front27x8.50-15Reference

Industrial rear15-19.5R4Reference

2WD Length280 cmReference

4WD Length270 cmReference

Width130 cmReference

Height (ROPS)215 cmReference

4WD Clearance (front axle)34 cmReference

2WD Clearance (front axle)34 cmReference

2WD Front tread104 cmReference

4WD Front tread109 cmReference

Rear tread102 to 129 cmReference

4WD hydro1179 kgReference

Kubota L2800 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps40Reference

Battery CCA490Reference

Battery volts12Reference

Total cold cranking amps490 CCAReference

Attachment overview

Front-end loaderReference

BackhoeReference

Additional Kubota implements included 40, 50 or 60-inch rear tillers and a 64- or 74-inch rear-mount snowblower.Reference

Kubota BH76 Backhoe

Backhoe typeKubota BH76 BackhoeReference

Transport height201 cmReference

2-Foot flat digging depth227 cmReference

Reach from pivot305 cmReference

Loading height171 cmReference

Bucket force1478 kgReference

Dipperstick force928 kgReference

Speeds

With 11.2-24 rear tires.Reference

General

Make & ModelKubotaReference

Rollover protective structureTwo-post ROPS. Foldable ROPS optional.Reference

Power

Max Power29 hpReference

PTO

PTO Power24 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Engine Speed on Rear PTO speed540@2,430 RPMReference

Steering & brakes

Brakesmechanical wet discReference

Steering typepowerReference

Hydraulics

Pump Rated Output (total)11.1 gpmReference

Hydraulics Typeopen centerReference

Remote Valves0 to 3 ValvesReference

Steering & Implements flow4.3 gpm (6.8 gpm)Reference

Rear Hitch category (SAE designation)Category IReference

Rear Hitch maximum lift capacity900.4 kgReference

Dimensions & weight

Wheelbase161 cmReference

Height Over ROPS215.9 cmReference

Overall Length280.9 cmReference

Overall Width130.6 cmReference

Front axle clearance34.5 cmReference

Overall weight1,179.3 kgReference

Wheels & tyres

Rear Wheel Type11.2-24Reference

Rear wheel tread range40.2 to 50.8 inchesReference

Front Wheel Type45,427Reference

Front Wheel tread range109.5 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
