Tractor · 1994Unverified
Kubota L2900
Kubota L2900 — Grand L Series · 32 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
32 hp
Weight
2560 to 2710 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS.Reference
Engine
Kubota 1.5L 3-cyl dieselReference
Engine (gross)23.9 kWReference
Engine (net)22.1 kWReference
Plows2Reference
Plows1Reference
Kubota D1503Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke84 x 91 mmReference
Power (net)22.1 kWReference
Power (gross)23.9 kWReference
Fuel systemindirect injectionReference
Rated RPM2700Reference
Torque96.1 NmReference
Starter volts12Reference
Coolant capacity7.0 LReference
Oil capacity3.5 LReference
Oil change100 hReference
Transmission
8-speed synchronized shuttleReference
8-speed power shuttleReference
TransmissionFSTReference
Typesynchronized shuttleReference
Gears8 forward and reverseReference
Clutchdry discReference
Oil capacity39.0 LReference
Four gears (1-4) in two ranges (low/high) with left-hand shuttle lever. Gear shifts (1-4) are synchronized using the foot clutch. Shuttle shifting is also synchronized using the clutch. The tractor must be stopped, and clutch used, to shift ranges.Reference
TransmissionGlide Shift (GST)Reference
Typepower shuttleReference
Eight-speed gear shift (1-8) with left-hand shuttle lever. Power shuttle shifting without need for the clutch. The transmission can be shifted (without the clutch) by sequentially shifting up through the gears.Reference
PTO & Hydraulics
PTO (claimed)18.6 kWReference
Hydraulic system39.0 LReference
Typeopen centerReference
Capacity39.0 LReference
Pressure171.7 barReference
Pump flow26.5 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)1301 kgReference
Rear lift (at 24"/610mm)997 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2670Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Engine RPM2000@2623Reference
Capacities
Fuel34.8 LReference
Dimensions
2WD Wheelbase167 cmReference
4WD Wheelbase166 cmReference
Weight2560 to 2710 poundsReference
Front tire5.00-15Reference
Rear tire11.2-24 (2WD)Reference
Weight215 kgReference
Standard tires (ag)Front: 5.00-15. Rear: 11.2-24 (2WD)Reference
Standard tires (ag)Front: 7.2-16. Rear: 11.2-24 (4WD)Reference
Length281 cmReference
Width132 cmReference
Height (steering wheel)151 cmReference
Height (ROPS)209 cmReference
Ground clearance32 cmReference
Front tread96/105/116/125 cmReference
Front tread110 cmReference
Rear tread103/112/121/130/140 cmReference
2WD ROPS1161 kgReference
4WD ROPS1229 kgReference
Max Drawbar498 kgReference
Kubota L2900 attachments
72" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
backhoeReference
L2900 Serial Numbers
19945002Reference
199554654Reference
199656282Reference
199758445Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery CCA490Reference
Battery volts12Reference
Attachment overview
72" mid-mount mower deckReference
SnowblowerReference
BladeReference
Kubota LA480 loaderReference
Kubota LA481 loaderReference
BackhoeReference
Maximum recommended trailer load for the L2900 is 3,300 pounds. Kubota recommended mowers up to 72-inches in width, 60-inch tillers, or a 52-inch box blade.Reference
72" Mower deck
Typemid-mount Kubota RC72-29Reference
Type3-blade with hydraulic liftReference
Cutting width182 cmReference
Overall width225 cmReference
Cut height3 to 10 cmReference
Kubota BL4690 Backhoe
Backhoe typeKubota BL4690 BackhoeReference
Transport height194 cmReference
Bucket width25 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width60 cmReference
Digging depth229 cmReference
Reach from pivot295 cmReference
Loading height191 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1338 kgReference
Dipperstick force789 kgReference
Speeds
With 11.2-24 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
