Tractor · 1978Unverified
Kubota L295
Kubota L295 — Compact Utility tractor · 26 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Max power
15.7 kW
Weight
2304 to 2895 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Manual steeringReference
Differential mechanical wet disc brakesReference
Two-post fixed ROPS.Reference
Variants
L295F2WDReference
L295DT4WDReference
Engine
Kubota 1.3L 3-cyl dieselReference
Fuel tank34.8 LReference
Engine22.4 kWReference
Drawbar (tested)15.7 kWReference
KubotaReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke82 x 82 mmReference
Power22.4 kWReference
Air cleanerpaper elementReference
Compression21:1Reference
Rated RPM2800Reference
Starter volts12Reference
Oil capacity6.1 LReference
Coolant capacity5.8 LReference
Power at rated engine speed19.7 kWReference
Max power15.7 kWReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)19.4 kWReference
PTO (tested)19.7 kWReference
Typeopen centerReference
Pump flow21.2 lpmReference
Rear TypeIReference
Rear PTOliveReference
Rear PTO Type540/700/1000Reference
Power at rated PTO speed18.6 kWReference
Dimensions
2WD Wheelbase165 cmReference
4WD Wheelbase166 cmReference
Weight2304 to 2895 poundsReference
Front tire5.00-15Reference
2WD Rear tire12.4-24Reference
2WD Standard tires (ag)Front: 5.00-15. Rear: 12.4-24Reference
4WD Standard tires (ag)Front: 7-16. Rear: 12.4-24Reference
Length284 cmReference
Width142 cmReference
Height140 cmReference
2WD Ground clearance35 cmReference
4WD Ground clearance31 cmReference
2WD Front tread102 to 134 cmReference
4WD Front tread109 cmReference
Rear tread112 to 149 cmReference
2WD Shipping1045 kgReference
4WD Shipping1179 kgReference
4WD Operating1313 kgReference
Kubota L295 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Kubota L4510 Backhoe
Backhoe typeKubota L4510 BackhoeReference
Transport height236 cmReference
Bucket width30 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Bucket width91 cmReference
2-Foot flat digging depth223 cmReference
Reach from pivot325 cmReference
Loading height213 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force3175 kgReference
Dipperstick force1814 kgReference
Test results
Diesel 8-speed 4WDOctober 7 - 17, 1980Link: Nebraska Tractor Test 1370 fileReference
PTO performanceReference
Fuel use7.2 l/hourReference
Fuel use6.4 l/hourReference
Drawbar performanceReference
Fuel use6.8 l/hourReference
Max pull1580 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
