Tractor · 1998Unverified
Kubota L3010
Kubota L3010 — Grand L10 Series · 32 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
32 hp
Weight
2700 to 2745 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post ROPS.Reference
Variants
L3010F2WD GearReference
L3010DT4WD GearReference
L3010GST4WD Glide ShiftReference
L3010HST4WD HydroReference
Engine
Kubota 1.5L 3-cyl dieselReference
Engine (gross)23.9 kWReference
Engine (net)22.7 kWReference
Kubota E-TVCS D1503Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke83 x 92 mmReference
Power (net)22.7 kWReference
Power (gross)23.9 kWReference
Fuel systemindirect injectionReference
Pre-heatingglow plugsReference
Rated RPM2700Reference
Starter volts12Reference
Coolant capacity7.0 LReference
Transmission
8-speed mechanical shuttleReference
hydrostaticReference
8-speed automatic fully synchronizedReference
16-speed creeperReference
TransmissionFSTReference
Typemechanical shuttleReference
Gears8 forward and reverseReference
Clutchdry discReference
Four synchronized gears in two ranges. Synchronized shuttle shifting.Reference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
TransmissionGlide Shift (GST)Reference
Typeautomatic fully synchronizedReference
The Glide Shift allows clutchless automatic shifting between gears.Reference
TypecreeperReference
Gears16 forward and reverseReference
Optional creeper range available for the FST or GST transmission.Reference
PTO & Hydraulics
Gear PTO (claimed)19.0 kWReference
Hydro PTO (claimed)17.9 kWReference
Hydraulic system39.0 LReference
Typeopen centerReference
Capacity39.0 LReference
Pump flow26.5 lpmReference
Steering flow17.8 lpmReference
Rear TypeIReference
Controlposition control and optional draft controlReference
Rear lift (at 24"/610mm)997 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Mid PTOsemi-independentReference
Mid PTO Type2000Reference
Capacities
Fuel34.8 LReference
Dimensions
Wheelbase166 cmReference
Weight2700 to 2745 poundsReference
Front tire5.00-15Reference
Rear tire12.4-24 (2WD)Reference
Weight215 kgReference
Standard tires (ag)Front: 5.00-15. Rear: 12.4-24 (2WD)Reference
Standard tires (ag)Front: 7.2-16. Rear: 12.4-24 (4WD)Reference
Length281 cmReference
Width144 cmReference
Height (ROPS)214 cmReference
Ground clearance35 cmReference
Front tread110 cmReference
Rear tread112/121/130/140 cmReference
DT1224 kgReference
GST1233 kgReference
HST1245 kgReference
Kubota L3010 attachments
72" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery CCA520Reference
Battery volts12Reference
Attachment overview
72" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
BackhoeReference
Advertised attachments for the L3010 included 60-inch rear-mount finish mowers (RCR60-CA), 60 or 72-inch rotary cutters (L360CA/L372CA), tillers (FL1021C, FL1271C/RS, FL1521C, L60CA), post-hole diggers (BL80A), box scrapers (L7554), and 60-inch front-mount rotary brooms (L2062A).Reference
72" Mower deck
Typemid-mount Kubota RC72-29AReference
Type3-blade with hydraulic liftReference
Cutting width182 cmReference
Overall width225 cmReference
Cut height3 to 8 cmReference
Kubota BL4690 Backhoe
Backhoe typeKubota BL4690 BackhoeReference
Bucket width25 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width60 cmReference
Digging depth229 cmReference
Reach from pivot295 cmReference
Loading height191 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1338 kgReference
Dipperstick force789 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
