Tractor · 1989Unverified

Kubota L3250

Name: Kubota L3250
Brand: Kubota

Kubota L3250 — L Series · 40 hp. Reference specifications; pending source verification.

The Kubota L3250 is a tractor rated at 40 hp, making it one of the more compact models in its class. Manufactured between 1989 and 1990, the L3250 is powered by a 4-cylinder diesel liquid-cooled engine, which is transmitted through a four-wheel drive system with an 8-speed gearbox. The listed weight of the tractor is 1247 kg. It is designed for working on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

40 hp

Weight

1247 kg

Catalogue coverage

Variants represented

Richest spec table

76 rows

Recorded power

40 hp

Recorded weight

1247 kg

Transmissions

8-speed mechanical shuttle

Production years

1989-1990

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Two- or four-wheel driveReference

SteeringpowerReference

Mechanical wet disc brakesReference

Two-post ROPS.Reference

Variants

L3250F2WDReference

L3250DT4WDReference

Engine

Kubota 1.9L 4-cyl dieselReference

Fuel tank29.1 LReference

Engine (gross)29.8 kWReference

Kubota V1902Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement1.9 LReference

Bore/Stroke84 x 81 mmReference

Power (gross)29.8 kWReference

Fuel systemdirect injectionReference

Rated RPM2600Reference

Starter volts12Reference

Coolant capacity7.0 LReference

Transmission

8-speed mechanical shuttleReference

Typemechanical shuttleReference

Gears8 forward and 7 reverseReference

PTO & Hydraulics

PTO (claimed)23.9 kWReference

Typeopen centerReference

Pump flow29.5 lpmReference

Rear TypeIReference

Rear lift850 kgReference

Rear PTOliveReference

Rear PTO Type540Reference

Dimensions

Wheelbase173 cmReference

Weight1247 kgReference

Front tire6.00-16Reference

Rear tire13.6-26Reference

Ag front6.00-16Reference

Ag rear13.6-26Reference

Lawn/turf front29x12.50-15 (Turf Special)Reference

Lawn/turf rear21.5-16.1 (Turf Special)Reference

Length290 cmReference

Width142 cmReference

Height204 cmReference

Kubota L3250 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

Kubota BF550 loaderReference

Kubota LA650A loaderReference

BackhoeReference

Kubota L4530B Backhoe

Backhoe typeKubota L4530B BackhoeReference

Transport height180 cmReference

Bucket width25 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width60 cmReference

Digging depth243 cmReference

Reach from pivot284 cmReference

Loading height179 cmReference

Bucket Rotation194°Reference

Swing Arc180°Reference

Bucket force1310 kgReference

Dipperstick force746 kgReference

Kubota L4560 Backhoe

Backhoe typeKubota L4560 BackhoeReference

Transport height266 cmReference

Bucket width33 cmReference

Bucket width45 cmReference

Bucket width60 cmReference

Bucket width76 cmReference

Digging depth251 cmReference

Reach from pivot373 cmReference

Loading height252 cmReference

Bucket Rotation190°Reference

Swing Arc180°Reference

Bucket force2231 kgReference

Dipperstick force1102 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
