Tractor · 1994Unverified
Kubota L3300
Kubota L3300 — Grand L Series · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
2610 to 2765 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS.Reference
Engine
Kubota 1.6L 3-cyl dieselReference
Fuel tank34.8 LReference
Engine (gross)26.2 kWReference
Engine (net)24.2 kWReference
Plows2 (12-inch)Reference
Plows1 (16-inch)Reference
Kubota D1703Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke86 x 91 mmReference
Power (net)24.2 kWReference
Power (gross)26.2 kWReference
Fuel systemindirect injectionReference
Rated RPM2700Reference
Torque105.6 NmReference
Starter volts12Reference
Coolant capacity7.0 LReference
Oil capacity3.5 LReference
Oil change100 hReference
Transmission
8-speed synchronized shuttleReference
8-speed power shuttleReference
TransmissionFSTReference
Typesynchronized shuttleReference
Gears8 forward and reverseReference
Clutchdry discReference
Oil capacity39.0 LReference
Four gears (1-4) in two ranges (low/high) with left-hand shuttle lever. Gear shifts (1-4) are synchronized using the foot clutch. Shuttle shifting is also synchronized using the clutch. The tractor must be stopped, and clutch used, to shift ranges.Reference
TransmissionGlide Shift (GST)Reference
Typepower shuttleReference
Eight-speed gear shift (1-8) with left-hand shuttle lever. Power shuttle shifting without need for the clutch. The transmission can be shifted (without the clutch) by sequentially shifting up through the gears.Reference
PTO & Hydraulics
PTO (claimed)20.9 kWReference
Typeopen centerReference
Pressure171.7 barReference
Total flow26.5 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)1301 kgReference
Rear lift (at 24"/610mm)997 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2670Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Engine RPM2000@2623Reference
Dimensions
2WD Wheelbase167 cmReference
4WD Wheelbase171 cmReference
Weight2610 to 2765 poundsReference
Front tire5.00-15Reference
Rear tire12.4-24 (2WD)Reference
Weight215 kgReference
Standard tires (ag)Front: 5.00-15. Rear: 12.4-24 (2WD)Reference
Standard tires (ag)Front: 7.2-16. Rear: 12.4-24 (4WD)Reference
Length284 cmReference
Width135 cmReference
Height (steering wheel)152 cmReference
Height (ROPS)213 cmReference
Ground clearance35 cmReference
Front tread96/105/116/125 cmReference
Front tread110 cmReference
Rear tread103/112/121/130/140 cmReference
2WD ROPS1183 kgReference
4WD ROPS1254 kgReference
Max Drawbar498 kgReference
Kubota L3300 attachments
72" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Battery CCA490Reference
Battery volts12Reference
Attachment overview
72" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
BackhoeReference
The maximum trailer load for the L3300 is 4,400 pounds. Kubota specified 72-inch mowers, 60-inch tillers, or a 52-inch box blade.Reference
72" Mower deck
Typemid-mount Kubota RC72-29Reference
Type3-blade with hydraulic liftReference
Cutting width182 cmReference
Overall width225 cmReference
Cut height3 to 10 cmReference
Kubota BL4690 Backhoe
Backhoe typeKubota BL4690 BackhoeReference
Transport height194 cmReference
Bucket width25 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width60 cmReference
Digging depth229 cmReference
Reach from pivot295 cmReference
Loading height191 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1338 kgReference
Dipperstick force789 kgReference
Speeds
With 12.4-24 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
