Tractor · 1982Unverified
Kubota L355
Kubota L355 — L Series · 29 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
29 hp
Weight
1369 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Engine
Kubota 1.7L 4-cyl dieselReference
Fuel tank33.3 LReference
Engine26.8 kWReference
Kubota V1701Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.7 LReference
Bore/Stroke82 x 82 mmReference
Power26.8 kWReference
Starter volts12Reference
Transmission
8-speed shuttleReference
TypeshuttleReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)21.6 kWReference
Typeopen centerReference
Pump flow23.8 lpmReference
Rear Type1Reference
Rear PTOliveReference
Rear PTO Type540Reference
Dimensions
Weight1369 kgReference
Front tire8.6-16Reference
Rear tire13.6-24Reference
Ag front8.6-16Reference
Ag rear13.6-24Reference
Length330 cmReference
Width163 cmReference
Height (exhaust)206 cmReference
Kubota L355 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Kubota L4510 Backhoe
Backhoe typeKubota L4510 BackhoeReference
Transport height236 cmReference
Bucket width30 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Bucket width91 cmReference
2-Foot flat digging depth223 cmReference
Reach from pivot325 cmReference
Loading height213 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force3175 kgReference
Dipperstick force1814 kgReference
Kubota L4530 Backhoe
Backhoe typeKubota L4530 BackhoeReference
Transport height186 cmReference
Bucket width25 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
2-Foot flat digging depth215 cmReference
Reach from pivot279 cmReference
Loading height185 cmReference
Bucket Rotation164°Reference
Swing Arc180°Reference
Bucket force746 kgReference
Dipperstick force1310 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
