Tractor · 2026Unverified
Kubota L3770
Kubota L3770 — L70 Series · 37 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Weight
3726 to 4034 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Original price was $31,829 in 2026Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Engine
Kubota 1.8L 3-cyl dieselReference
Engine (gross)27.6 kWReference
Kubota D1803Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke87 x 102 mmReference
Power (gross)27.6 kWReference
Fuel systemcommon rail direct injectionReference
Rated RPM2600Reference
Torque114.2 NmReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
PTO (claimed)20.9 kWReference
Rear valves3Reference
Pump flow30.4 lpmReference
Rear TypeIReference
Rear lift (at ends)1700 kgReference
Rear lift (at 24"/610mm)1200 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2491Reference
Dimensions
Wheelbase180 cmReference
Weight3726 to 4034 poundsReference
Front tire7.00-16Reference
Rear tire12.4-24Reference
Standard tires (ag)Front: 7.00-16. Rear: 12.4-24Reference
Length294 cmReference
Width151 cmReference
Height (ROPS)246 cmReference
Height (cab)231 cmReference
ROPS Weight1690 kgReference
Cab Weight1829 kgReference
Ground clearance36 cmReference
Front tread115 cmReference
Rear tread119 to 148 cmReference
Kubota L3770 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Battery CCA582Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Kubota BH92A Backhoe
Backhoe typeKubota BH92A BackhoeReference
Transport height260 cmReference
2-Foot flat digging depth265 cmReference
Reach from pivot381 cmReference
Loading height224 cmReference
Bucket Rotation180°Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
