Tractor · 2026Unverified

Kubota L3770

Name: Kubota L3770
Brand: Kubota

Kubota L3770 — L70 Series · 37 hp. Reference specifications; pending source verification.

The Kubota L3770 is a compact tractor model with a rated output of 37 hp. It was manufactured in 2026. The tractor is equipped with a 3-cylinder diesel liquid-cooled engine, which powers a four-wheel drive system via a hydrostatic transmission. Its listed weight is 3726 to 4034 pounds, with an intended application for work areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

37 hp

Weight

3726 to 4034 pounds

Catalogue coverage

Variants represented

Richest spec table

60 rows

Recorded power

37 hp

Recorded weight

1690 kg

Transmissions

hydrostatic

Production years

2026-2026

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Original price was $31,829 in 2026Reference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional with air-conditioning.Reference

Engine

Kubota 1.8L 3-cyl dieselReference

Engine (gross)27.6 kWReference

Kubota D1803Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.8 LReference

Bore/Stroke87 x 102 mmReference

Power (gross)27.6 kWReference

Fuel systemcommon rail direct injectionReference

Rated RPM2600Reference

Torque114.2 NmReference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

PTO (claimed)20.9 kWReference

Rear valves3Reference

Pump flow30.4 lpmReference

Rear TypeIReference

Rear lift (at ends)1700 kgReference

Rear lift (at 24"/610mm)1200 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2491Reference

Dimensions

Wheelbase180 cmReference

Weight3726 to 4034 poundsReference

Front tire7.00-16Reference

Rear tire12.4-24Reference

Standard tires (ag)Front: 7.00-16. Rear: 12.4-24Reference

Length294 cmReference

Width151 cmReference

Height (ROPS)246 cmReference

Height (cab)231 cmReference

ROPS Weight1690 kgReference

Cab Weight1829 kgReference

Ground clearance36 cmReference

Front tread115 cmReference

Rear tread119 to 148 cmReference

Kubota L3770 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery CCA582Reference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Kubota BH92A Backhoe

Backhoe typeKubota BH92A BackhoeReference

Transport height260 cmReference

2-Foot flat digging depth265 cmReference

Reach from pivot381 cmReference

Loading height224 cmReference

Bucket Rotation180°Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
