Tractor · 2011Unverified

Kubota L3800

Name: Kubota L3800
Brand: Kubota

Kubota L3800 — Standard L Series · 37 hp. Reference specifications; pending source verification.

The Kubota L3800 is a compact tractor with a rated output of 37 hp, positioning it as one of the more compact options in its class. The L3800 was manufactured from 2011 to 2014. It features a 3-cylinder diesel liquid-cooled engine, which drives through a mechanical front-wheel drive system with a hydrostatic transmission. The tractor weighs between 2480 and 2668 pounds, making it suitable for tasks of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

37 hp

Max power

37.4 hp

Weight

2480 to 2668 pounds

Catalogue coverage

Variants represented

Richest spec table

125 rows

Recorded power

37 hp

Transmissions

8-speed constant mesh gear

Production years

2011-2014

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Original price$14,185 (2011 2WD gear)Reference

Original price16,908 (2011 4WD hydro)Reference

Drive4x2 2WDReference

Drive4x4 MFWD 4WD (optional)Reference

Differential lockrear standardReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Foldable two-post ROPS.Reference

Variants

L3800F2WD gearReference

L3800DT4WD gearReference

L3800HST4WD hydroReference

Engine

Kubota 1.8L 3-cyl dieselReference

Engine (gross)27.9 kWReference

Engine (net)22.6 kWReference

Kubota D1803Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.8 LReference

Bore/Stroke86 x 102 mmReference

EmissionsInterim Tier IVReference

Power (net)22.6 kWReference

Power (gross)27.9 kWReference

Rated RPM2700Reference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders3 cylinderReference

Rated engine speed2,700 RPMReference

Emissions complianceInterim Tier IVReference

Bore and stroke3.4x4.0 inchesReference

Cooling systemliquid-cooledReference

Transmission

8-speed constant mesh gearReference

hydrostaticReference

Typeconstant mesh gearReference

Gears8 forward and 4 reverseReference

ClutchdryReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Oil capacity23.5 LReference

Transmission TypeGearReference

Wheel Drive2 WD | 4 WDReference

PTO & Hydraulics

PTO (claimed)23.5 kWReference

PTO (claimed)22.6 kWReference

Hydraulic system26.9 LReference

Hydraulic system23.5 LReference

Typeopen centerReference

Capacity26.9 LReference

Capacity23.5 LReference

Pump flow23.8 lpmReference

Total flow38.2 lpmReference

Steering flow14.4 lpmReference

Rear TypeIReference

Rear lift (at ends)906 kgReference

Rear lift (at 24"/610mm)650 kgReference

Rear PTOliveReference

Rear PTO Type540Reference

Engine RPM540@2425 (gear)Reference

Engine RPM540@2580 (hydro)Reference

Capacities

Fuel37.9 LReference

Fuel tank37.9 LReference

Dimensions

Wheelbase160 cmReference

Weight2480 to 2668 poundsReference

Front tire5.00-15Reference

Rear tire11.2-24 (2WD)Reference

Standard tires (ag)Front: 5.00-15. Rear: 11.2-24 (2WD)Reference

Standard tires (ag)Front: 7.2-16. Rear: 11.2-24 (4WD)Reference

Lawn/turf front23x8.50-12 (2WD)Reference

Lawn/turf front25x8.50-14 (4WD)Reference

Lawn/turf rear13.6-16Reference

Industrial front27x8.50-15 (4WD)Reference

Industrial rear15-19.5Reference

Length280 cmReference

Length270 cmReference

Width139 cmReference

Height (ROPS)232 cmReference

Ground clearance34 cmReference

Front tread104 cmReference

Front tread109 cmReference

Rear tread111 to 129 cmReference

1124 kgReference

1205 kgReference

1210 kgReference

Kubota L3800 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps40Reference

Charging volts12Reference

Battery CCA490Reference

Battery volts12Reference

Total cold cranking amps490 CCAReference

Attachment overview

Front-end loaderReference

BackhoeReference

Kubota BH77 Backhoe

Backhoe typeKubota BH77 BackhoeReference

2-Foot flat digging depth234 cmReference

Reach from pivot315 cmReference

Loading height167 cmReference

Bucket force1551 kgReference

Dipperstick force993 kgReference

Speeds

With 11.2-24 R1 rear tires.Reference

General

Make & ModelKubotaReference

Cruise controlAvailableReference

SCV controljoystickReference

Rollover protective structureFoldable two-post ROPS.Reference

Power

Max Power37.4 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Engine Speed on Rear PTO speed540@2,580 RPMReference

Steering & brakes

Brakeswet discReference

Steering typeHydrostatic PowerReference

Hydraulics

Pump Rated Output (total)10.1 gpmReference

Hydraulics Typeopen centerReference

Steering & Implements flow3.8 gpm (6.3 gpm)Reference

Rear Hitch category (SAE designation)Category IReference

Rear Hitch maximum lift capacity906.3 kgReference

Dimensions & weight

Height Over ROPS232.9 cmReference

Overall Length280.9 cmReference

Overall Width140 cmReference

Overall weight1,210.2 kgReference

Wheels & tyres

Rear wheel tread range43.8 to 50.8 inchesReference

Front Wheel tread range109.5 cmReference

Operator station

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
