Tractor · 2026Unverified

Kubota L3970

Name: Kubota L3970
Brand: Kubota

Kubota L3970 — L70 Series · 39 hp. Reference specifications; pending source verification.

The Kubota L3970 is a tractor model with a rating of approximately 39 hp, positioning it at the lower end of its class. Produced in 2026, it features a 3-cylinder turbocharged diesel liquid-cooled engine, coupled with four-wheel drive and a hydrostatic transmission. The tractor has an operating weight range of 4057 to 4387 pounds. It is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

39 hp

Weight

4057 to 4387 pounds

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

39 hp

Recorded weight

1840 kg

Transmissions

hydrostatic

Production years

2026-2026

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Original price was $34,979 in 2026Reference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional with air-conditioning.Reference

Engine

Kubota 1.8L 3-cyl dieselReference

Engine (gross)29.1 kWReference

Kubota D1803Reference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.8 LReference

Bore/Stroke87 x 102 mmReference

Power (gross)29.1 kWReference

Fuel systemcommon rail direct injectionReference

Rated RPM2300Reference

Torque148.3 NmReference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

PTO (claimed)23.0 kWReference

Rear valves3Reference

Pump flow37.2 lpmReference

Rear TypeIReference

Rear lift (at ends)1700 kgReference

Rear lift (at 24"/610mm)1200 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2299Reference

Dimensions

Wheelbase195 cmReference

Weight4057 to 4387 poundsReference

Front tire7.00-16Reference

Rear tire12.4-24Reference

Standard tires (ag)Front: 7.00-16. Rear: 12.4-24Reference

Length309 cmReference

Width151 cmReference

Height (ROPS)246 cmReference

Height (cab)231 cmReference

ROPS Weight1840 kgReference

Cab Weight1989 kgReference

Ground clearance34 cmReference

Front tread115 cmReference

Rear tread119 to 148 cmReference

Kubota L3970 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery CCA582Reference

Battery CCA680Reference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Kubota BH92A Backhoe

Backhoe typeKubota BH92A BackhoeReference

Transport height260 cmReference

2-Foot flat digging depth265 cmReference

Reach from pivot381 cmReference

Loading height224 cmReference

Bucket Rotation180°Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
