Tractor · 2013Unverified

Kubota L4060

Name: Kubota L4060
Brand: Kubota

Kubota L4060 — L60 Series · 42 hp. Reference specifications; pending source verification.

The Kubota L4060 is a compact tractor model, rated at 42 hp, making it suitable for a range of applications. It was manufactured from 2013 to 2025 and features a 4-cylinder diesel liquid-cooled engine, driving through a four-wheel drive system with a hydrostatic transmission. The listed weight of the tractor is between 3737 and 4134 pounds, and it is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

42 hp

Max power

42 hp

Weight

3737 to 4134 pounds

Catalogue coverage

Variants represented

Richest spec table

139 rows

Recorded power

42 hp

Transmissions

8-speed synchronized shuttle

Production years

2013-2025

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Original price was $33,564 in 2025Reference

Four-wheel driveReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Two-post foldable ROPS. Grand Cab with air-conditioning available with hydrostatic.Reference

Variants

L4060DT4WDReference

L4060GST4WD 12-speedReference

L4060HSThydrostaticReference

L4060HSTChydro cabReference

Engine

Kubota 2.4L 4-cyl dieselReference

Fuel tank51.1 LReference

Engine (gross)31.3 kWReference

Engine (net)29.8 kWReference

KubotaReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.4 LReference

Bore/Stroke86 x 102 mmReference

EmissionsTier IVReference

Emission controlexhaust gas recirculation (EGR)Reference

Power (net)29.8 kWReference

Power (gross)31.3 kWReference

Fuel systemdirect injectionReference

Rated RPM2700 (gear)Reference

Rated RPM2600 (hydro)Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

No of Cylinders4Reference

Rated engine speed2,700 rpmReference

Bore and stroke87 X 102.4 mmReference

Transmission

8-speed synchronized shuttleReference

12-speedReference

hydrostaticReference

Typesynchronized shuttleReference

Gears8 forward and reverseReference

Clutchmechanical dry discReference

TransmissionKubota Glide ShiftReference

Gears12 forward and 8 reverseReference

Clutchhydraulic dry discReference

TransmissionHST PlusReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Hydrostatic transmission with three ranges plus Hydro Dual Speed Hi-Lo. The Dual Speed allows rapid switching between two speeds in range, either automatically or with a lever on the steering column.Reference

Transmission TypeHSTReference

forward and reverse options3 RangesReference

forward speed range1.5 - 25.7 km/hReference

reverse speed range1.4 - 24.5 km/hReference

Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)25.4 kWReference

PTO (claimed)24.2 kWReference

Gear Pump flow37.1 lpmReference

Hydro Pump flow35.6 lpmReference

Gear Total flow55.6 lpmReference

Hydro Total flow53.4 lpmReference

Gear Steering flow18.5 lpmReference

Hydro Steering flow17.8 lpmReference

Rear TypeIReference

Controlposition control, draft control optionalReference

Rear lift (at 24"/610mm)1251 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Mid PTOoptionalReference

Mid PTO Type2000Reference

Dimensions

Wheelbase189 cmReference

Weight3737 to 4134 poundsReference

Front tire8.3-16Reference

Rear tire14.9-24Reference

Ag front8.3-16Reference

Ag rear14.9-24Reference

Length308 cmReference

Width168 cmReference

Height (ROPS)247 cmReference

Height (cab)231 cmReference

Ground clearance30 cmReference

Flange rear axleReference

Front tread130 cmReference

Rear tread128/143/152 cmReference

1695 kgReference

1700 kgReference

1705 kgReference

1875 kgReference

Kubota L4060 attachments

snowblowerReference

bladeReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

ROPS Charging amps40Reference

Cab Charging amps60Reference

Battery volts12Reference

Battery size12 VReference

Alternator size12 VReference

Attachment overview

SnowblowerReference

BladeReference

Front-end loaderReference

BackhoeReference

Kubota BH92 Backhoe

Backhoe typeKubota BH92 BackhoeReference

Transport height254 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width60 cmReference

Bucket width76 cmReference

Bucket width91 cmReference

Digging depth278 cmReference

Loading height214 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force2062 kgReference

Dipperstick force1223 kgReference

Capacities

Capacity2,434 ccReference

Power

Max Power42 hpReference

PTO

PTO Power32.5 hpReference

Rear PTO PowerTRUEReference

Rear PTO ControlIndependentReference

Rear PTO RPM540 rpmReference

Mid PTO RPM2,000 rpmReference

Steering & brakes

BrakesWet disc typeReference

Steering typeHydrostatic power steeringReference

Hydraulics

Pump Rated Output (total)53.5 l/minReference

Hydraulics Type3-point: Category 1Reference

Remote Valves3Reference

Steering & Implements flow17.9 lpm (35.6 lpm)Reference

Rear Hitch category (SAE designation)Category IReference

General

SCV controlJoystickReference

Rear tread spacing1,530 mmReference

Dimensions & weight

Overall Height2,480 mmReference

Overall Length3,085 mmReference

Overall Width1,690 mmReference

Turning radius8.9 feet (with Brakes)Reference

Overall weight1,875.1 kgReference

Wheels & tyres

Rear Wheel Type14.9-24Reference

Front Wheel Type8.3-16Reference

Front Wheel tread range1,155 mmReference

Operator station

Cab AvailabilityOptionalReference

Seat SuspensionAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
