Tractor · 1986Unverified

Kubota L4150DTN

Name: Kubota L4150DTN
Brand: Kubota

Kubota L4150DTN · 40 hp. Reference specifications; pending source verification.

The Kubota L4150DTN is a tractor with a rated power of 40 hp, which places it at the lighter end of its class. This model was produced from 1986 to 1990. It features a 5-cylinder diesel liquid-cooled engine, paired with four-wheel drive and an 8-speed gearbox. The tractor has an operating weight of 1880 kg and is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

40 hp

Weight

1880 kg

Catalogue coverage

Variants represented

Richest spec table

55 rows

Recorded power

40 hp

Recorded weight

1880 kg

Transmissions

8-speed partially synchronized

Production years

1986-1990

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Four-wheel driveReference

SteeringpowerReference

Mechanical wet disc brakesReference

Two-post ROPS with optional sunshade.Reference

Variants

L4150F2WDReference

L4150DT4WDReference

L4150DTNnarrowReference

Engine

Kubota 2.3L 5-cyl dieselReference

Engine37.3 kWReference

Kubota F2302-D1-2Reference

dieselReference

5-cylinderReference

liquid-cooledReference

Displacement2.3 LReference

Bore/Stroke84 x 81 mmReference

Power37.3 kWReference

Air cleanerdual dry elementsReference

Rated RPM2600Reference

Oil capacity11.4 LReference

Coolant capacity7.6 LReference

Transmission

8-speed partially synchronizedReference

Typepartially synchronizedReference

Gears8 forward and reverseReference

Clutchsingle dry plateReference

Oil capacity40.1 LReference

PTO & Hydraulics

PTO (claimed)29.8 kWReference

Hydraulic system40.1 LReference

Typeopen centerReference

Capacity40.1 LReference

Pressure172.4 barReference

Valves0 or 1Reference

Pump flow34.1 lpmReference

Rear TypeIReference

Rear lift (at ends)1598 kgReference

Rear lift (at 24"/610mm)1202 kgReference

Rear PTOindependentReference

Rear PTO Type540/750Reference

Capacities

Fuel46.2 LReference

Dimensions

Wheelbase199 cmReference

Weight1880 kgReference

Front tire8-16Reference

Rear tire13.6-24Reference

Ag front8-16Reference

Ag rear13.6-24Reference

Ag front7-16Reference

Ag rear12.4-24Reference

Ag rear14.9-24Reference

Ag rear18.4-24Reference

Length355 cmReference

Width132 cmReference

Height (steering wheel)146 cmReference

Ground clearance28 cmReference

Front tread109 cmReference

Rear tread99 to 157 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
