Tractor · 1998Unverified
Kubota L4310
Kubota L4310 — Grand L10 Series · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
2875 to 3520 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Drive4x2 2WD (L4310F)Reference
Drive4x4 MFWD 4WDReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Variants
L4310F2WDReference
L4310DT4WD gearReference
L4310GST4WD Glide-ShiftReference
L4310HSThydroReference
L4310HSTChydro cabReference
Engine
Kubota 2.2L 4-cyl dieselReference
Engine (gross)33.8 kWReference
Engine (net)32.1 kWReference
Kubota E-TVCSReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke87 x 92 mmReference
Power (net)32.1 kWReference
Power (gross)33.8 kWReference
Rated RPM2600Reference
Starter volts12Reference
Coolant capacity7.5 LReference
Transmission
8-speed mechanical shuttleReference
hydrostaticReference
8-speed automatic fully synchronizedReference
16-speed creeperReference
TransmissionFSTReference
Typemechanical shuttleReference
Gears8 forward and reverseReference
Clutchdry discReference
Four synchronized gears in two ranges. Synchronized shuttle shifting.Reference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
TransmissionGlide Shift (GST)Reference
Typeautomatic fully synchronizedReference
The Glide Shift allows clutchless automatic shifting between gears.Reference
TypecreeperReference
Gears16 forward and reverseReference
Optional creeper range available for the FST or GST transmission.Reference
PTO & Hydraulics
Gear PTO (claimed)28.0 kWReference
Hydro PTO (claimed)26.8 kWReference
Hydraulic system39.0 LReference
Typeopen centerReference
Capacity39.0 LReference
Pump flow29.5 lpmReference
Steering flow15.5 lpmReference
Rear Type1Reference
Controlposition control and optional draft controlReference
Rear lift (at 24"/610mm)1047 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Capacities
Fuel34.8 LReference
Dimensions
2WD Wheelbase181 cmReference
4WD Wheelbase180 cmReference
Weight2875 to 3520 poundsReference
Front tire6.00-16Reference
Rear tire14.9-24 (2WD)Reference
Standard tires (ag)Front: 6.00-16. Rear: 14.9-24 (2WD)Reference
Standard tires (ag)Front: 8.30-16. Rear: 14.9-24 (4WD)Reference
2WD Length302 cmReference
4WD Length298 cmReference
Width158 cmReference
Height (ROPS)215 cmReference
Height (cab)220 cmReference
Ground clearance38 cmReference
Front tread114/124/134/144 cmReference
Front tread115 cmReference
Rear tread118/119/130/145/154 cmReference
1304 kgReference
1374 kgReference
1378 kgReference
1388 kgReference
1596 kgReference
Kubota L4310 attachments
bladeReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40 (ROPS)Reference
Charging amps55 (cab)Reference
Battery CCA582Reference
Battery volts12Reference
Attachment overview
BladeReference
Front-end loaderReference
BackhoeReference
Advertised attachments for the L4310 included 72-inch rear-mount finish mowers (RCR72-CA) and rotary cutters (L372CA), tillers (FL1521C, L60CA), post-hole diggers (BL80A), and box scrapers (L7554).Reference
Kubota BL4690 Backhoe
Backhoe typeKubota BL4690 BackhoeReference
Bucket width25 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width60 cmReference
Digging depth229 cmReference
Reach from pivot295 cmReference
Loading height191 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1338 kgReference
Dipperstick force789 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
