Tractor · 2004Unverified
Kubota L4400
Kubota L4400 — Model year 2004-20072008-2010 · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
3153 to 3307 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Differential lockrear standardReference
Power steeringReference
Wet disc brakesReference
Foldable two-post ROPS. Sunshade optional.Reference
Variants
L4400F2WD gearReference
L4400DT4WD gearReference
L4400HST4WD hydroReference
Engine
Kubota 2.2L 4-cyl dieselReference
Engine (gross)33.8 kWReference
Engine (net)32.1 kWReference
KubotaReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke87 x 92 mmReference
Power (net)32.1 kWReference
Power (gross)33.8 kWReference
Rated RPM2600Reference
Starter volts12Reference
Oil capacity7.6 LReference
Coolant capacity6.5 LReference
Transmission
hydrostaticReference
8-speed constant meshReference
2WD gear1497 kgReference
4WD gear1430 kgReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
Oil capacity45.0 LReference
Originally only available with a gear transmission, the hydrostatic was made an option on the L4400 in 2006.Reference
Typeconstant meshReference
Gears8 forward and 4 reverseReference
Oil capacity40.1 LReference
Four gears (1-4) in two ranges (Low/High) and reverse (R). Mechanical shuttle shifting between forward-low and reverse.Reference
PTO & Hydraulics
PTO (claimed)28.0 kWReference
Gear Hydraulic system40.1 LReference
Hydro Hydraulic system45.0 LReference
Typeopen centerReference
Gear Capacity40.1 LReference
Hydro Capacity45.0 LReference
Valves0 to 3Reference
Pump flow31.8 lpmReference
Total flow51.1 lpmReference
Steering flow19.3 lpmReference
Rear TypeIReference
Rear lift (at ends)1301 kgReference
Rear lift (at 24"/610mm)1047 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2475Reference
Capacities
Fuel42.8 LReference
Dimensions
2WD Wheelbase184 cmReference
4WD Wheelbase184 cmReference
Weight3153 to 3307 poundsReference
Front tire7.5L-15Reference
2WD Rear tire14.9-24Reference
2WD Standard tires (ag)Front: 7.5L-15. Rear: 14.9-24Reference
4WD Standard tires (ag)Front: 8.3-16. Rear: 14.9-24Reference
2WD Optional tires (ag)Front: 6.00-16. Rear: 14.9-24Reference
Ag front6.0-16Reference
Ag rear14.9-24Reference
Lawn/turf front27x8.50-15Reference
Lawn/turf rear44x8.50-20Reference
Industrial front10.0-16.5Reference
Industrial rear17.5-24Reference
2WD Length286 cmReference
4WD Length300 cmReference
Width158 cmReference
Height (ROPS)216 cmReference
2WD Clearance (front axle)39 cmReference
4WD Clearance (front axle)39 cmReference
2WD Front tread128 to 157 cmReference
4WD Front tread115 cmReference
Rear tread118 to 154 cmReference
4WD hydro1500 kgReference
Kubota L4400 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery CCA582Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Additional Kubota implements included 40, 50 or 60-inch rear tillers and a 64- or 74-inch rear-mount snowblower.Reference
Kubota BH92 Backhoe
Backhoe typeKubota BH92 BackhoeReference
Transport height254 cmReference
2-Foot flat digging depth277 cmReference
Reach from pivot382 cmReference
Loading height221 cmReference
Bucket force2062 kgReference
Dipperstick force1223 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
